MP75A4 Nidec DC Drives

MP75A4 on Powermatic Associates
Nidec

Part#:MP75A4

Manufacturer:Nidec

Category:DC Drives

Product Lifecycle:Active

Product description

NIDEC MP75A4 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter designed for 2 quadrant operation with air cooling. It operates within an ambient air temperature range of -15°C to +60°C and has a rated current of 75A. The supply voltage ranges from 24Vac to 480Vac, accommodating multiple standards including 48Vac, 120Vac, 220Vac, 230Vac, 240Vac, 380Vac, 400Vac, and 415Vac. This model features a frame size 1A with dimensions of H17.48" x W11.54" x D8.74" (H444mm x W293mm x D222mm) and is protected by an IP20 enclosure. It supports a 3-phase input network and offers a variety of communication protocols such as EtherCAT, PROFIBUS, Ethernet, DeviceNet, CANopen, and INTERBUS. The MP75A4 includes 3 digital outputs (240mA / 0-24Vdc; source) and 2 digital outputs (5A / 240Vac; source; relay contact type), alongside 1 analog input (-10Vdc to 10Vdc; differential) and 2 analog inputs (0-20mA / 4-20mA / -10Vdc to 10Vdc; single-ended) with respective conversion resolutions of 14-bit and 10-bit. Additionally, it features 3 digital inputs (0-24Vdc), a rated active power of 27kW, rated power of 45HP, and 2 analog outputs (0-20mA / 4-20mA / -10Vdc to 10Vdc; source; single-ended; 10-bit conversion resolution).

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

Manufacturer warranty

MP75A4 Nidec

Get a quick Quote!

Request a quote, and we will send you price and availability within minutes.

Select Qty:

Average response time: 11 minutes

Worldwide Shipping and Delivery

Secure Payment Processing

Warranty

Responsive Customer Support

Got Questions? We've Got Answers!

Need more details?

Feel free to chat with us

About the manufacturer

Nidec

Powermatic Associates is an authorized Nidec distributor, proudly offering a vast array of high-quality industrial products designed to meet your most demanding operational needs. Nidec, a global leader in motor and control technology, is renowned for its cutting-edge innovations in electric motors and related components that enhance efficiency and performance across various industries. As a manuf...
