M700-09501040E10101AB100 Nidec Servo Motor Drives

M700-09501040E10101AB100 on Powermatic Associates
Nidec

Part#:M700-09501040E10101AB100

Manufacturer:Nidec

Category:Servo Motor Drives

Product Lifecycle:Active

Product description

NIDEC M700-09501040E10101AB100 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the M700 series designed with a built-in brake transistor, single Safe Torque Off (STO), and requires an external choke with air cooling for operation. It features frame size 9E with dimensions of H39.7" x W12.21" x D11.42" (H1010mm x W310mm x D290mm). This model supports multiple communication protocols including Ethernet, Ethernet/IP, Modbus TCP, and PROFINET RT. It operates with a rated current of 125A under normal duty and 104A under heavy-duty conditions, and it is designed for a supply voltage range of 500Vac-575Vac. The ambient air temperature for operation ranges from -20°C to +40°C. It has an IP20, NEMA 1, UL open degree of protection, and is suitable for a 3-phase input network with a frequency of 45-66 Hz (supply input) and can output frequencies from 0-599 Hz. The device includes 2 analog outputs, 6 digital inputs, and 4 digital outputs, with analog inputs featuring 11-bit conversion resolution. It is rated for an active power of 110kW under normal duty and 75kW under heavy-duty, corresponding to 125HP and 100HP respectively.

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

Manufacturer warranty

M700-09501040E10101AB100 Nidec
