8096957 Festo Ball Valves

8096957 on Powermatic Associates
Festo

Part#:8096957

Alt. Part#:VZBE-11/2-T-63-F-3T-F0507-M-V15V15

Manufacturer:Festo

Category:Ball Valves

Product Lifecycle:Active

Product description

ball valve VZBE-11/2-T-63-F-3T-F0507-M-V15V15 Design structure: (* 3-way ball valve, * T hole), Type of actuation: mechanical, Sealing principle: soft, Assembly position: Any, Mounting type: Line installation

Product Details

  • Sealing principle
    Soft
  • Switching position indication
    Slot direction = flow direction
  • Nominal pressure of fitting PN
    63
  • Symbol
    00991888
  • Flow rate Kv type T corner
    20.2 m³/h
  • Material number of housing
    1.4408
  • Material number for ball
    1.4408
  • Product weight
    3600 g
  • Actuation type
    Mechanical
  • Type of mounting
    Line installation
  • Based on norm
    ASME B1.20.1 ISO 5211
  • Housing material
    Cast stainless steel
  • Shaft material
    High-alloy stainless steel
  • Certification
    CRN
  • Seat seal material
    PTFE
  • Inside diameter
    32 mm
  • Valve function
    3/2
  • Explosion prevention and protection
    Zone 1 (ATEX) Zone 22 (ATEX)
  • Type code
    VZBE
  • Fitting connection
    1 1/2 NPT
  • Flow direction
    Reversible
  • Medium
    Vapor Neutral liquids
  • Seals material
    PTFE
  • CE marking (see declaration of conformity)
    as per EU pressure equipment directive
  • Design
    3-way ball valve Drilled T hole
  • Mounting position
    Any
  • Flange hole pattern
    F0507
  • Nominal width DN
    40
  • Breakaway torque at differential pressure, nominal pressure, fitting PN
    45.5 Nm
  • Temperature of medium
    -20 °C ... 200 °C
  • Note on materials
    Contains paint-wetting impairment substances RoHS-compliant
  • Ball material
    Cast stainless steel
  • Material number for shaft
    1.4401
  • Corrosion resistance class (CRC)
    4 - Particularly high corrosion stress

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
