8073839 Festo Vacuum Cups
Part#:8073839
Alt. Part#:OGVM-80-A-N-G14F
Manufacturer:Festo
Category:Vacuum Cups
Product Lifecycle:Active
Product description
suction cup OGVM-80-A-N-G14F Suction cup height compensator: 22 mm, Min. workpiece radius: 75 mm, Nominal size: 8 mm, suction cup diameter: 80 mm, suction cup volume: 64 cm3
Product Details
- Min. workpiece radius 75 mm
- Type code OGVM
- Ambient temperature -20 °C ... 80 °C
- Shore hardness 60 +/- 5
- Nominal width 8 mm
- Symbol 00991485
- Operating pressure -0.95 bar ... 0 bar
- Type of mounting Via vacuum connection
- Color Black
- Suction cup height compensation 22 mm
- Suction cup volume 64 cm³
- Mounting position Any
- Suction cup shape Round bellows, 1.5 convolutions
- Lateral force at nominal operating pressure 225 N
- Vacuum connection G1/4
- Note on materials RoHS-compliant
- Operating medium Atmospheric air based on ISO 8573-1:2010 [7:-:-]
- Corrosion resistance class (CRC) 2 - Moderate corrosion stress
- Holding force at nominal operating pressure 246 N
- Suction cup material NBR
- Suction cup diameter 80 mm
- Connection position Top
- Nominal operating pressure -0.6 bar
- Product weight 75 g
- Material of screwed trunnion Wrought aluminum alloy
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
