8068929 Festo Quarter Turn Actuators

Name: 8068929
Brand: Festo

Part#:8068929

Manufacturer:Festo

Alt. Part#:DFPD-N-700-RP-90-RS60-F1012

Product Lifecycle:Active

Get a quick Quote!

semi-rotary drive DFPD-N-700-RP-90-RS60-F1012 single-acting, rack and pinion design, connection pattern to NAMUR VDI/VDE 3845 for mounting solenoid valves, position sensors and positioners, standard connection to process valve fitting ISO 5211, NPT contro

About the manufacturer: Festo is one of the manufacturers that offers Quarter Turn Actuators that you can order at Powermatic Associates site. Festo Corp. has been a top supplier of automation and intelligent automation solutions for more than four decades in the United States and eight decades globally. The company is committed to transforming the manufacturing sector and enhancing business efficiency.

Check out the 8068929 Festo price in the box on the right side or send a quick quote.

Product Details

Operating pressure
2 bar ... 8 bar
Safety function
The fundamental safety function is that the control valve moves to the switching position when the compressed air is turned off. It is reset by spring force.
MTTFd
1126 years
Depth shaft connection
29 mm
Type code
DFPD
Symbol
00991266
Type of ignition protection for gas
Ex h IIC T4 Gb X
Explosion prevention and protection
Zone 1 (ATEX) Zone 22 (ATEX)
Nominal operating pressure
6 bar
Swivel angle
90 deg
Flange hole pattern
F1012
Mounting position
Any
ATEX category gas
II 2G
ATEX category for dust
II 2D
Operating medium
Compressed air as per ISO 8573-1:2010 [7:4:4]
Note about the torque
The actuator's operating torque must not be higher than the maximum permissible torque listed in ISO 5211, based on the size of the mounting flange and the coupling.
Pneumatic connection
1/4 NPT
Material of piston
Die-cast aluminum
Devices type according to VDMA 66413
Safety device
Maritime classification
See certificate

Standard connection for valve

ISO 5211

Closing direction

Clockwise closing

Certified for safety function to ISO 13849 and IEC 61508 (SIL)

Product can be used in safety-related parts of control systems up to SIL 2, low demand up to SIL 3 in a redundant architecture

Certificate issuing authority

DNVGL TAP00001CE German Technical Control Board (TÜV) Rheinland 968/V 1106.00/19

Torque at nominal operating pressure and 0° swivel angle

465.5 Nm

Storage temperature

-20 °C ... 60 °C

Product weight

26268 g

Cover material

Die-cast aluminum, coated

Housing material

Wrought aluminum alloy, anodized

Material of screws

High-alloy stainless steel

Design

Gear rack/pinion

Size of valve actuator

700

PFH

1.01E-7

End-position adjusting range at nominal swivel angle

-5 deg ... 5 deg

Mode of operation

Single-acting

Connection for valve positioner and position sensor conforms to standard

VDI/VDE 3845 size AA 2

Safety integrity level (SIL)

Up to SIL 2 low demand mode up to SIL 1 high demand mode

Explosive ambient temperature

-20°C <= Ta <= +80°C

Corrosion resistance class (CRC)

2 - Moderate corrosion stress

Air consumption at 6 bar per cycle 0°-nominal swivel angle-0°

24.5 l

Material of spring

Spring steel

Cam material

Steel

End-position adjusting range at 0°

-5 deg ... 5 deg

Valve connection conforms to standard

VDI/VDE 3845 (NAMUR)

Type of (ignition) protection for dust

Ex h IIIC T105°C Db X

Ambient temperature

-20 °C ... 80 °C

CE marking (see declaration of conformity)

as per EU explosion protection directive (ATEX)

PFD

7.8E-4

Spring return torque with 90° swivel angle

470.7 Nm

Seals material

NBR

Shaft material

Steel, nickel-plated

Information on operating and pilot media

Dew point min. 10 °C below the ambient and medium temperature Operation with oil lubrication possible (required for further use)

Torque at nominal operating pressure and 90° swivel angle

252.8 Nm

Spring return torque at 0° swivel angle

258.1 Nm

Shaft connection

T27

Material of sub-base

Wrought aluminum alloy, anodized

Note on materials

RoHS-compliant

Material of bearing

POM

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
