8030609 Festo Quarter Turn Actuators
Part#:8030609
Alt. Part#:DAPS-0480-090-R-F1012-T4
Manufacturer:Festo
Category:Quarter Turn Actuators
Product Lifecycle:Active
Product description
semi-rotary drive DAPS-0480-090-R-F1012-T4 double-acting, air connection to VDI/VDE 3845 Namur valves, direct flange mounting, high-temperature version. Size of actuator: 0480, Flange hole pattern: (* F10, * F12), Swivel angle: 90 deg, End-position adjust
Product Details
- Flange hole pattern F10 F12
- Type code DAPS
- End-position adjusting range at 0° -1 deg ... 9 deg
- Mounting position Any
- Symbol 00991265
- Nominal operating pressure 5.6 bar
- Ambient temperature -20 °C ... 150 °C
- Operating medium Compressed air as per ISO 8573-1:2010 [7:4:4]
- Pneumatic connection G1/4
- Material number for shaft 1.4305
- Size of valve actuator 0480
- Depth shaft connection 29.5 mm
- Mode of operation Double-acting
- Valve connection conforms to standard VDI/VDE 3845 (NAMUR)
- Type of ignition protection for gas Ex h IIC T6...T3 Gb X
- Explosive ambient temperature -20°C <= Ta <= +150°C
- Information on operating and pilot media Operation with oil lubrication possible (required for further use)
- Note about the torque The actuator's operating torque must not be higher than the maximum permissible torque listed in ISO 5211, based on the size of the mounting flange and the coupling.
- Cushioning No cushioning
- Closing direction Clockwise closing
- ATEX category gas II 2G
- CE marking (see declaration of conformity) as per EU explosion protection directive (ATEX)
- Torque at nominal operating pressure and 50° swivel angle 240 Nm
- Product weight 9600 g
- Cover material Wrought aluminum alloy
- Material of screws High-alloy steel
- Swivel angle 90 deg
- Standard connection for valve ISO 5211
- Position sensing None
- Operating pressure 3 bar ... 8.4 bar
- Type of (ignition) protection for dust Ex h IIIC T85°C...T200°C Db X
- Corrosion resistance class (CRC) 3 - High corrosion stress
- Torque at nominal operating pressure and 90° swivel angle 360 Nm
- Air consumption at 6 bar per cycle 0°-nominal swivel angle-0° 18.2 l
- Note on materials Contains paint-wetting impairment substances RoHS-compliant
- Housing material Wrought aluminum alloy
- Design Scotch yoke system
- Safety integrity level (SIL) Up to SIL 2 high demand mode Up to SIL 2 low demand mode
- ATEX category for dust II 2D
- Explosion prevention and protection Zone 1 (ATEX) Zone 22 (ATEX)
- Torque at nominal operating pressure and 0° swivel angle 480 Nm
- Shaft connection T27
- Seals material FPM PTFE-reinforced
- Shaft material High-alloy steel
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
