564107 Festo Compressed Air Preparation Units

564107 on Powermatic Associates
Festo

Part#:564107

Alt. Part#:MS9-LF-G-EUV

Manufacturer:Festo

Category:Compressed Air Preparation Units

Product Lifecycle:Active

Product description

filter MS9-LF-G-EUV 40 µm filter, metal bowl guard, fully automatic condensate drain, flow direction from left to right. Size: 9, Series: MS, Assembly position: Vertical +/- 5°, Grade of filtration: 40 µm, Condensate drain: fully automatic

Product Details

  • Condensate drain
    Fully automatic
  • Storage temperature
    5 °C ... 60 °C
  • Product weight
    2000 g
  • Note on materials
    RoHS-compliant
  • Housing material
    Die-cast aluminum
  • Separating disc material
    POM
  • Size
    9
  • Series
    MS
  • Max. condensate volume
    220 ml
  • Design
    Sinter filter with centrifugal separator
  • Ambient temperature
    5 °C ... 60 °C
  • Material of spin disc
    POM
  • Material of mounting bracket
    Die-cast aluminum
  • Module connector material
    Die-cast aluminum
  • Mounting position
    Vertical +/- 5°
  • Symbol
    00991520
  • Corrosion resistance class (CRC)
    2 - Moderate corrosion stress
  • Temperature of medium
    5 °C ... 60 °C
  • Material of filter support
    POM
  • Material of bowl
    Wrought aluminum alloy
  • Grade of filtration
    40 µm
  • Air quality class at the output
    Compressed air as per ISO 8573-1:2010 [7:8:4]
  • Covering material
    PA-reinforced
  • Compressed air filter material
    PE
  • Inspection window material
    PA
  • Type code
    MS9-LF
  • Operating pressure
    2 bar ... 12 bar
  • Operating medium
    Compressed air as per ISO 8573-1:2010 [7:9:-] Inert gas
  • Type of mounting
    Optionally: With accessories
  • Material of sub-base
    Die-cast aluminum
  • Shell sealing material
    NBR

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
