562051 Festo Vacuum Valves

Product Details

• Actuation type
  Electrical
• Operating voltage
  24V DC
• Width dimension
  20 mm
• Type code
  MHA1
• Suitability for vacuum
  yes
• Width
  20 mm
• Reset method
  Mechanical spring
• Exhaust air function
  Without flow control option
• Standard flow rate
  30 l/min
• Coil characteristics
  24 V DC: low-current phase 0.7 W, high-current phase 3.0 W
• Temperature of medium
  -5 °C ... 50 °C
• Pneumatic connection 2
  QS-3
• Housing material
  PA-reinforced PPS-reinforced
• Operating pressure
  0 bar ... 1.5 bar
• Sealing principle
  Soft
• Symbol
  00992254
• On switching time
  6 ms
• CE marking (see declaration of conformity)
  As per EU EMC directive
• Corrosion resistance class (CRC)
  2 - Moderate corrosion stress
• Type of mounting
  With through-hole
Material of screws
Steel
Valve function
2x2/2 closed, monostable
Standard nominal flow rate
30 l/min
Degree of protection
IP40
Mounting position
Any
Type of control
Direct
Signal status display
LED
Max. switching frequency
10 Hz
Duty cycle
100%
Operating medium
Compressed air as per ISO 8573-1:2010 [7:4:4]
Storage temperature
-20 °C ... 60 °C
Electrical connection
KMH plug
Pneumatic connection 1
QS-3
Note on materials
Free of copper and PTFE RoHS-compliant
Max. cable length
30 m
Pneumatic working port
QS-3
Nominal width
1.5 mm
Manual override
Non-detenting
Flow direction
Non-reversible
Operating pressure, reversible
-0.95 bar ... 0 bar
Permissible voltage fluctuations
+/- 10 %
Vibration resistance
Transport application test with severity level 2 as per FN 942017-4 and EN 60068-2-6
Product weight
30.6 g
Switching time off
6 ms
Information on operating and pilot media
Operation with oil lubrication possible (required for further use)
Shock resistance
Shock test with severity level 2 as per FN 942017-5 and EN 60068-2-27
Ambient temperature
-5 °C ... 50 °C
Pneumatic connection 11
QS-3
Seals material
FPM NBR
