553010 Festo Compressed Air Preparation Units
Part#:553010
Alt. Part#:MS9-LFM-1-AUV-DA
Manufacturer:Festo
Category:Compressed Air Preparation Units
Product Lifecycle:Active
Product description
micro filter MS9-LFM-1-AUV-DA 0.01 µm filter, metal bowl guard, fully automatic condensate drain, with differential pressure indicator, flow direction from left to right. Series: MS, Size: 9, Design structure: Fibre filter, Grade of filtration: 0,01 µm, C
Product Details
- Size 9
- Operating pressure 2 bar ... 12 bar
- Air quality class at the output Compressed air as per ISO 8573-1:2010 [1:7:2]
- Operating medium Compressed air as per ISO 8573-1:2010 [6:8:4]
- Temperature of medium 5 °C ... 60 °C
- Mounting position Vertical +/- 5°
- Corrosion resistance class (CRC) 2 - Moderate corrosion stress
- Differential pressure display Visual display
- Covering material PA
- Seals material NBR
- Series MS
- Design Fiber filter
- Min. standard flow rate for air quality class 325 l/min
- Max. condensate volume 225 ml
- Pneumatic connection 1 G1
- Pneumatic connection 2 G1
- Inspection window material PA
- Symbol 00991544
- Max. standard flow rate for air quality class 6500 l/min
- Ambient temperature 5 °C ... 60 °C
- Residual oil content 0.01 mg/m³
- Type of mounting Optionally: With accessories
- Compressed air filter material Borosilicate fiber
- Type code MS9-LFM
- Grade of filtration 0.01 µm
- Filter efficiency 99.9999 %
- Storage temperature -10 °C ... 60 °C
- Housing material Die-cast aluminum
- Condensate drain Fully automatic Manual, non-detenting
- Material of bowl Wrought aluminum alloy
- Product weight 2000 g
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
