550135 Festo Servo Motors

Product Details

• Rotor position sensor
  Absolute encoder, single-turn
• Insulation protection class
  F
• Rotor position sensor resolution
  18 bit
• Type of winding switch
  Star inside
• Winding inductance phase-phase
  13.44 mH
• Degree of protection
  IP54
• Nominal torque
  20.05 Nm
• Permissible axial shaft load
  200 N
• MTTFd, subcomponent
  152 years, rotor position sensor
• Electrical connection technology
  Plug
• Rotor position sensor interface
  EnDat® 22
• Max. rotational speed
  2460 1/min
• Phase-phase winding resistance
  1.41 Ohm
• Certification
  RCM compliance mark c UL us - Recognized (OL)
• MTTF, subcomponent
  76 years, rotor position sensor
• Conforms to standard
  IEC 60034
• Temperature monitoring
  PTC resistor
• Motor nominal power
  4420 W
• Motor nominal current
  7.8 A
• Rating class according to EN 60034-1
  S1
Peak current
20 A
Storage temperature
-20 °C ... 60 °C
Total output inertia moment
19.027 kgcm²
Rotor position sensor measuring principle
Inductive
Motor constants
2.72 Nm/A
Corrosion resistance class (CRC)
2 - Moderate corrosion stress
Ambient temperature
-10 °C ... 40 °C
Stall torque
25.48 Nm
Product weight
16200 g
Note on materials
RoHS-compliant
Number of pole pairs
6
Type code
EMMS-AS
Nominal rotary speed
2000 1/min
DC nominal voltage
565 V
Voltage constant, phase-to-phase
162.39 mVmin
CE marking (see declaration of conformity)
As per EU EMC directive As per EU low voltage directive
Relative air humidity
0 - 90 %
Peak torque
48.8 Nm
Permissible radial shaft load
1060 N
