546799 Festo Proximity Sensors

Name: 546799
Brand: Festo

Part#:546799

Manufacturer:Festo

Alt. Part#:SME-8M-DO-24V-K-7,5-OE

Product Lifecycle:Active

Get a quick Quote!

proximity sensor SME-8M-DO-24V-K-7,5-OE Electric, with reed contact, for drives with T-slot, assembly from above, with cable. Authorisation: (* RCM Mark, * c UL us - Listed (OL)), CE mark (see declaration of conformity): to EU directive for EMC, Special c

About the manufacturer: Festo is one of the manufacturers that offers Proximity Sensors that you can order at Powermatic Associates site. Festo Corp. has been a top supplier of automation and intelligent automation solutions for more than four decades in the United States and eight decades globally. The company is committed to transforming the manufacturing sector and enhancing business efficiency.

Check out the 546799 Festo price in the box on the right side or send a quick quote.

Product Details

Max. output current
80 mA
Special features
Oil-resistant
Switching output
Contact-based, bipolar
Electrical connection 1, connection type
Cable
CE marking (see declaration of conformity)
As per EU EMC directive
Ambient temperature
-40 °C ... 70 °C
Max. switching capacity DC
2.4 W
Voltage drop
4.25 V
DC operating voltage range
5 V ... 30 V
Type of mounting
Screwed tightly Can be inserted in slot from above
Switching status indication
LED yellow
Electrical connection 1, number of pins/wires
3
Certification
RCM compliance mark c UL us - Listed (OL)
Measuring principle
Magnetic reed
Min. switching capacity AC
2.4 VA
Max. switching capacity AC in mounting kits
2.4 VA
Overload protection
Not available
Connection outlet orientation
Longitudinal
Cable characteristic
Standard + cable chain
Degree of protection
IP65 IP68

Type code

SME

Symbol

00991622

Max. output current in mounting kits

80 mA

Product weight

87.1 g

Electrical connection 1, connection technology

Open end

Note on materials

Free of copper and PTFE RoHS-compliant

Switching element function

N/C contact

Max. switching capacity DC in mounting kits

2.4 W

Short-circuit protection

Reverse polarity protection

Cable length

7.5 m

Ambient temperature with flexible cable installation

-5 °C ... 70 °C

Operating voltage range AC

5 V ... 30 V

Connector cable test conditions

Flexural strength: as per Festo standard Cable chain: 5 million cycles, bending radius 75 mm

Material of cable sheath

TPE-U(PUR)

Housing material

PA High-alloy stainless steel

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
