5394665 Festo Compressed Air Preparation Units
Part#:5394665
Alt. Part#:PCRP-64-N14-7-C-R1-M-T19
Manufacturer:Festo
Category:Compressed Air Preparation Units
Product Lifecycle:Active
Product description
filter regulator PCRP-64-N14-7-C-R1-M-T19 Size: 64, Series: P, Actuator lock: Adjusting screw with lock, Assembly position: Vertical +/- 5°, Grade of filtration: 5 µm
Product Details
- Drain screw material number 1.4404/316L
- Material number of housing 1.4409/CF3M(316L)
- Series P
- Design Filter regulator without pressure gauge
- Pressure regulation range 0.5 bar ... 7 bar
- Standard nominal flow rate 2040 l/min
- Air quality class at the output Compressed air as per ISO 8573-1:2010 [6:4:4]
- Temperature of medium -60 °C ... 80 °C
- Pneumatic connection 2 NPT1/4-18
- Seals material CR VMQ
- Material of adjusting screw High-alloy stainless steel
- Compressed air filter material number 1.4404/316L
- Actuator lock Adjusting screw with lock
- Mounting position Vertical +/- 5°
- Operating pressure 0.1 MPa ... 2 MPa
- Max. standard flow rate 2410 l/min
- Operating medium Compressed air as per ISO 8573-1:2010 [-:4:-] Inert gas
- Pressure gauge connection G1/4
- Type of mounting Optionally: With mounting kit
- Material of spring High-alloy stainless steel
- Size 64
- Filter support material number 1.4409/CF3M(316L)
- Grade of filtration 5 µm
- Max. condensate volume 30 ml
- Pressure gauge G1/4 prepared
- Information on operating and pilot media Operation with oil lubrication possible (required for further use)
- Product weight 1965 g
- Note on materials Contains paint-wetting impairment substances RoHS-compliant
- Compressed air filter material High-alloy stainless steel
- Bowl material number 1.4409/CF3M (316L)
- Type code PCRP
- Condensate drain Manually rotating
- Symbol 00991586
- Max. pressure hysteresis 0.2 bar
- Storage temperature -60 °C ... 80 °C
- Pneumatic connection 1 NPT1/4-18
- Material of filter support Cast stainless steel
- Material of bowl Cast stainless steel
- Drain screw material High-alloy stainless steel
- Conforms to standard NACE MR0175/ISO 15156 (housing and bowl)
- Controller function With primary pressure compensation With secondary exhausting
- Explosion prevention and protection Observe the information on the certificate Zone 22 (ATEX)
- Ambient temperature -60 °C ... 80 °C
- Material of mounting bracket High-alloy stainless steel
- Housing material Cast stainless steel
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
