526263 Festo Compressed Air Preparation Units

526263 on Powermatic Associates
Festo

Part#:526263

Alt. Part#:LR-1/8-D-7-MICRO

Manufacturer:Festo

Category:Compressed Air Preparation Units

Product Lifecycle:Active

Product description

pressure regulator LR-1/8-D-7-MICRO With threaded connection plate and pressure gauge Size: Micro, Series: D, Actuator lock: Rotary knob with lock, Assembly position: Any, Design structure: directly-controlled diaphragm regulator

Product Details

  • Size
    Micro
  • Series
    D
  • Symbol
    00991538
  • Temperature of medium
    -10 °C ... 60 °C
  • Note on materials
    RoHS-compliant
  • Mounting position
    Any
  • Operating pressure
    1 bar ... 10 bar
  • Standard nominal flow rate
    230 l/min
  • Air quality class at the output
    Compressed air as per ISO 8573-1:2010 [7:4:4] Inert gas
  • Pneumatic connection 1
    G1/8
  • Housing material
    Wrought aluminum alloy
  • Type code
    LR
  • Design
    Directly controlled diaphragm regulator
  • Pressure regulation range
    0.5 bar ... 7 bar
  • Ambient temperature
    -10 °C ... 60 °C
  • Pneumatic connection 2
    G1/8
  • Diaphragm material
    NBR
  • Maritime classification
    See certificate
  • Actuator lock
    Rotary knob with detent
  • Pressure gauge
    with pressure gauge
  • Max. pressure hysteresis
    0.3 bar
  • Operating medium
    Compressed air as per ISO 8573-1:2010 [7:4:4] Inert gas
  • Type of mounting
    Optionally: With accessories
  • Seals material
    NBR
  • Controller function
    With secondary exhausting
  • Product weight
    110 g
  • Material of sub-base
    Wrought aluminum alloy

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
