4810855 Festo Ball Valves

Name: 4810855
Brand: Festo

Part#:4810855

Manufacturer:Festo

Alt. Part#:VZBF-11/2-P1-20-D-2-F0507-V15V15

Product Lifecycle:Active

Get a quick Quote!

ball valve VZBF-11/2-P1-20-D-2-F0507-V15V15 Stainless steel, 2/2-way, nominal width 11/2", top flange F0507, PN20, ANSI class 150. Design structure: 2-way ball valve, Type of actuation: mechanical, Sealing principle: soft, Assembly position: Any, Mounting

About the manufacturer: Festo is one of the manufacturers that offers Ball Valves that you can order at Powermatic Associates site. Festo Corp. has been a top supplier of automation and intelligent automation solutions for more than four decades in the United States and eight decades globally. The company is committed to transforming the manufacturing sector and enhancing business efficiency.

Check out the 4810855 Festo price in the box on the right side or send a quick quote.

Product Details

Product weight
5630 g
Design
2-way ball valve
Fitting connection
Flange as per ANSI B16.5 class 150
Valve function
2/2
Breakaway torque at differential pressure, nominal pressure, fitting PN
30 Nm
Symbol
00991458
Flow rate Kv
61.6 m³/h
Shaft material
High-alloy stainless steel
Sealing principle
Soft
Type of mounting
Line installation
Flange hole pattern
F0507
Flow direction
Reversible
Medium
Vapor Neutral liquids
Seals material
FPM PTFE
Material number of housing
1.4408
Switching position indication
Slot direction = flow direction
Nominal width DN
40
Based on norm
ANSI B16.5 class150 ISO 5211
Housing material
Cast stainless steel
Ball material
Cast stainless steel

Material number for shaft

1.4401

CE marking (see declaration of conformity)

as per EU pressure equipment directive

Type code

VZBF

Mounting position

Any

Inside diameter

38 mm

Nominal pressure of fitting PN

Note on materials

Contains paint-wetting impairment substances RoHS-compliant

Temperature of medium

-20 °C ... 200 °C

Material number for ball

1.4408

Certification

API607 CRN

Actuation type

Mechanical

Explosion prevention and protection

Zone 1 (ATEX) Zone 22 (ATEX)

Corrosion resistance class (CRC)

4 - Particularly high corrosion stress

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
