4745218 Festo Ball Valves

4745218 on Powermatic Associates
Festo

Part#:4745218

Alt. Part#:VZBE-3/4-T-63-D-2-M-V15V15

Manufacturer:Festo

Category:Ball Valves

Product Lifecycle:Active

Product description

ball valve VZBE-3/4-T-63-D-2-M-V15V15 Stainless steel, manual version, 2/2-way, nominal width 3/4", PN63, ASME B1.20.1 - NPT. Design structure: 2-way ball valve with hand lever, Type of actuation: mechanical, Sealing principle: soft, Assembly position: An

Product Details

  • Actuation type
    Mechanical
  • Inside diameter
    20 mm
  • Flow direction
    Reversible
  • Material number of housing
    1.4408
  • Certification
    CRN
  • Sealing principle
    Soft
  • Switching position indication
    Slot direction = flow direction
  • Based on norm
    ASME B1.20.1
  • Temperature of medium
    -20 °C ... 200 °C
  • Ball material
    Cast stainless steel
  • Product weight
    500 g
  • Type code
    VZBE
  • Design
    2-way ball valve with hand lever
  • Type of mounting
    Line installation
  • Valve function
    2/2
  • Nominal pressure of fitting PN
    63
  • Note on materials
    Contains paint-wetting impairment substances RoHS-compliant
  • Material number for ball
    1.4408
  • Corrosion resistance class (CRC)
    3 - High corrosion stress
  • Seat seal material
    PTFE
  • Fitting connection
    3/4 NPT
  • Breakaway torque at differential pressure, nominal pressure, fitting PN
    7.5 Nm
  • Medium
    Vapor Neutral liquids
  • Housing material
    Cast stainless steel
  • Shaft material
    High-alloy stainless steel
  • Explosion prevention and protection
    Zone 1 (ATEX) Zone 22 (ATEX)
  • Mounting position
    Any
  • Nominal width DN
    20
  • Symbol
    00991458
  • Flow rate Kv
    15.6 m³/h
  • Seals material
    PTFE
  • Material number for shaft
    1.4401

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

4745218 Related Documents

4745218 DataSheet.pdf

Manufacturer warranty

4745218 Festo

Get a quick Quote!

Request a quote, and we will send you price and availability within minutes.

Select Qty:

Average response time: 11 minutes

Worldwide Shipping and Delivery

Secure Payment Processing

Warranty

Responsive Customer Support
