35412 Festo Vacuum Cups
Part#:35412
Alt. Part#:VASB-30-1/8-NBR
Manufacturer:Festo
Category:Vacuum Cups
Product Lifecycle:Active
Product description
suction cup VASB-30-1/8-NBR With sealing ring OL. Nominal size: 3 mm, suction cup diameter: 30 mm, Effective suction diameter: 25 mm, Position of connection: on top, Suction cup shape: Round, bellows 1.5 conv
Product Details
- Type code VASB
- Mounting thread G1/8
- Material of screwed trunnion Brass
- Connection position Top
- Suction cup shape Round bellows, 1.5 convolutions
- Breakaway force at 70% vacuum 34 N
- Shore hardness 60 +/- 5
- Nominal width 3 mm
- Operating medium Atmospheric air based on ISO 8573-1:2010 [7:-:-]
- Holding force at nominal operating pressure 34 N
- Note on materials RoHS-compliant
- Suction cup diameter 30 mm
- Symbol 00991485
- Suction cup mounting G 1/8
- Vacuum connection G1/8
- Effective suction cup diameter 25 mm
- Ambient temperature -20 °C ... 80 °C
- Color Black
- Suction cup material NBR
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
35412 Related Documents
Manufacturer warranty
35412 Festo
Get a quick Quote!
Request a quote, and we will send you price and availability within minutes.
Select Qty:
Average response time: 11 minutes
Worldwide Shipping and Delivery
Secure Payment Processing
Warranty
Responsive Customer Support
Got Questions? We've Got Answers!
Need more details?
Feel free to chat with us
Compare 35412 with other Vacuum Cups products
Type code
Mounting thread
Material of screwed trunn...
Connection position
Suction cup shape
Breakaway force at 70% va...
Shore hardness
Nominal width
Operating medium
Holding force at nominal ...
Selected product
35412
Festo
suction cup VASB-30-1/8-NBR With sealing ring OL. Nominal size: 3 mm, suction cup diameter: 30 mm, E...
Type codeVASB
Mounting threadG1/8
Material of screwed trunnionBrass
Connection positionTop
Suction cup shapeRound bellows, 1.5 convoluti...
Breakaway force at 70% vacuum34 N
Shore hardness60 +/- 5
Nominal width3 mm
Operating mediumAtmospheric air based on ISO...
Holding force at nominal operating pressure34 N
36144
Festo
suction cup VAS-55-1/4-NBR With sealing ring OL. Nominal size: 4 mm, suction cup diameter: 55 mm, Ef...
Type codeVAS
Mounting threadG¼
Material of screwed trunnion-
Connection positionTop
Suction cup shapeRound, flat
Breakaway force at 70% vacuum106 N
Shore hardness-
Nominal width4 mm
Operating mediumAtmospheric air based on ISO...
Holding force at nominal operating pressure-
About the manufacturer
Powermatic Associates is an authorized Festo distributor, proudly offering a wide array of Festo's innovative industrial automation products and solutions. Festo is a globally recognized leader in automation technology and pneumatic solutions, renowned for their commitment to quality, efficiency, and sustainability. With a vast portfolio ranging from actuators, valves, sensors, and connectors to e...
About the Product Category
Devices known as vacuum cups are utilized in the automation of manufacturing processes to effectively grasp and elevate objects. They generate suction force through pneumatic vacuum generators, thereby improving both productivity and precision. Vacuum cups come in a variety of types, including flat, oval, and bellows suction cups, each designed to manage specific surfaces and workpieces. Their fun...
