2900543 Festo Electrical Peripheral Devices

2900543 on Powermatic Associates
Festo

Part#:2900543

Alt. Part#:CPX-CTEL-2-M12-5POL-LK

Manufacturer:Festo

Category:Electrical Peripheral Devices

Product Lifecycle:Active

Product description

electrical interface CPX-CTEL-2-M12-5POL-LK Dimensions W x L x H: (* (including interlinking block), * 50 mm x 107 mm x 55 mm), Diagnosis: (* Communication error, * Short circuit module, * Module-oriented diagnostics, * Undervoltage), Parameters configuri

Product Details

  • Parameterization
    Diagnostic behavior Module parameters
  • Power failure buffering
    10 ms
  • Max. address capacity outputs
    32 byte
  • IO-Link®, number of ports
    2
  • Dimensions W x L x H
    (incl. interlinking block) 50 mm x 107 mm x 55 mm
  • Intrinsic current consumption at nominal operating voltage
    Typ. 65 mA
  • Ambient temperature
    -5 °C ... 50 °C
  • Product weight
    110 g
  • IO-Link®, protocol version
    Master V 1.0
  • Electrical connection
    2x socket M12
  • Note on materials
    RoHS-compliant
  • Type code
    CPX
  • Control elements
    DIL switch
  • Corrosion resistance class (CRC)
    1 - Low corrosion stress (when installed)
  • Electrical isolation between channels
    no
  • Protocol
    IO-Link®
  • IO-Link®, port class
    A B
  • IO-Link®, output current
    1.6 A PL/port 1.6 A PS/port
  • Diagnostics
    Communication error Undervoltage
  • LED indicators
    PS: electronic supply, sensor supply Group diagnostics
  • Nominal operating voltage DC
    24 V
  • Storage temperature
    -20 °C ... 70 °C
  • Max. address capacity inputs
    32 byte
  • IO-Link®, process data width OUT
    4/4 to 16/6 bytes parameterizable
  • IO-Link®, minimum cycle time
    Min. 1 ms per 1 byte of process data
  • DC operating voltage range
    18 V ... 30 V
  • Electrical isolation between channel and internal bus
    Yes, when using intermediate feed
  • Degree of protection
    IP65 IP67
  • IO-Link®, communication mode
    COM1 (4.8 kBd), COM2 (38.4 kBd), COM3 (230.4 kBd)
  • IO-Link®, process data width IN
    4/4 to 16/6 bytes parameterizable
  • Max. cable length
    20 m
  • Housing material
    PA-reinforced PC

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
