1491999 Festo Process & Media Valves

Name: 1491999
Brand: Festo

Festo 1491999 solenoid valve VZWD-L-M22C-M-G14-25-V-3AP4-22 Directly actuated, G1/4" connection. Design structure: Directly actuated poppet valve, Type of actuation: electrical, Sealing principle: soft, Assembly position: Any, Mounting type: Line installation

Part#:1491999

Manufacturer:Festo

Alt. Part#:VZWD-L-M22C-M-G14-25-V-3AP4-22

Product Lifecycle:Active

Get a quick Quote!

solenoid valve VZWD-L-M22C-M-G14-25-V-3AP4-22 Directly actuated, G1/4" connection. Design structure: Directly actuated poppet valve, Type of actuation: electrical, Sealing principle: soft, Assembly position: Any, Mounting type: Line installation

About the manufacturer: Festo is one of the manufacturers that offers Process & Media Valves that you can order at Powermatic Associates site. Festo Corp. has been a top supplier of automation and intelligent automation solutions for more than four decades in the United States and eight decades globally. The company is committed to transforming the manufacturing sector and enhancing business efficiency.

Check out the 1491999 Festo price in the box on the right side or send a quick quote.

Product Details

Nominal width
2.5 mm
Type of control
Direct
Type code
VZWD
Mounting position
Any
Valve function
2/2, closed, monostable
Differential pressure
0 bar
Max. viscosity
22 mm²/s
Sealing principle
Soft
Electrical connection
Form A Rectangular design
Nominal pressure of fitting PN
100
Reset method
Mechanical spring
Temperature of medium
-10 °C ... 80 °C
On switching time
20 ms
Degree of protection
IP65
Design
Directly controlled poppet valve
Type of mounting
Line installation
Manual override
None
Medium
Compressed air as per ISO 8573-1:2010 [7:4:4] Other flow media on request
Permissible voltage fluctuations
+/- 10 %
Symbol
00992979

Leak rate to EN 12266-1

Note on materials

Contains paint-wetting impairment substances RoHS-compliant

Product weight

550 g

Actuation type

Electrical

Fitting connection

G1/4

Flow direction

Non-reversible

Insulation class

Duty cycle

100%

Ambient temperature

-10 °C ... 35 °C

Material number of housing

CW617N

Housing material

Cast brass

Coil characteristics

230 V AC: 50/60 Hz, initial power 18.0 VA, holding power 15.0 VA

Medium pressure

0 bar ... 22 bar

Flow rate Kv

0.16 m³/h

Switching time off

18 ms

CE marking (see declaration of conformity)

As per EU low voltage directive

Standard nominal flow rate

170 l/min

Seals material

FPM

Corrosion resistance class (CRC)

1 - Low corrosion stress

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
