1395690 Festo Vacuum Cups
Part#:1395690
Alt. Part#:VASB-30-1/8-PUR-B
Manufacturer:Festo
Category:Vacuum Cups
Product Lifecycle:Active
Product description
suction cup VASB-30-1/8-PUR-B Suction cup height compensator: 13,9 mm, Nominal size: 3 mm, suction cup diameter: 30 mm, suction cup volume: 6,18 cm3, Effective suction diameter: 24,8 mm
Product Details
- Suction cup height compensation 13.9 mm
- Suction cup volume 6.18 cm³
- Mounting position Any
- Operating medium Atmospheric air based on ISO 8573-1:2010 [7:-:-]
- Color Blue
- Suction cup material PUR
- Suction cup diameter 30 mm
- Connection position Top
- Nominal operating pressure -0.7 bar
- Vacuum connection G1/8
- Material of screwed trunnion Brass
- Operating pressure -0.95 bar ... 0 bar
- Ambient temperature -20 °C ... 60 °C
- Holding force at nominal operating pressure 34 N
- Nominal width 3 mm
- Type code VASB
- Symbol 00991485
- Product weight 14 g
- Shore hardness 60 +/- 5
- Note on materials RoHS-compliant
- Effective suction cup diameter 24.8 mm
- Suction cup shape Round bellows, 1.5 convolutions
- Corrosion resistance class (CRC) 2 - Moderate corrosion stress
- Type of mounting Via vacuum connection
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
