1378427 Festo Vacuum Cups
Part#:1378427
Alt. Part#:VASB-75-1/4-SI-B
Manufacturer:Festo
Category:Vacuum Cups
Product Lifecycle:Active
Product description
suction cup VASB-75-1/4-SI-B Sealing ring is not included in the scope of delivery. Suction cup height compensator: 15,5 mm, Nominal size: 4 mm, suction cup diameter: 75 mm, suction cup volume: 65,5 cm3, Position of connection: on top
Product Details
- Suction cup diameter 75 mm
- Connection position Top
- Symbol 00991485
- For use in the food industry See supplementary material information
- Product weight 78 g
- Operating pressure -0.95 bar ... 0 bar
- Ambient temperature -40 °C ... 200 °C
- Holding force at nominal operating pressure 228 N
- Suction cup material VMQ (silicone)
- Suction cup volume 65.5 cm³
- Suction cup shape Round bellows, 1.5 convolutions
- Type of mounting Via vacuum connection
- Shore hardness 60 +/- 5
- Suction cup height compensation 15.5 mm
- Type code VASB
- Nominal operating pressure -0.7 bar
- Corrosion resistance class (CRC) 2 - Moderate corrosion stress
- Vacuum connection G1/4
- Note on materials Contains paint-wetting impairment substances RoHS-compliant
- Nominal width 4 mm
- Mounting position Any
- Operating medium Atmospheric air based on ISO 8573-1:2010 [7:-:-]
- Color Transparent
- Material of screwed trunnion Wrought aluminum alloy
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
