FAZ-S20/1 Eaton Supplementary Protectors

FAZ-S20/1 on Powermatic Associates
Eaton

Part#:FAZ-S20/1

Manufacturer:Eaton

Category:Supplementary Protectors

Product Lifecycle:Active

Product description

FAZ-S20/1 Eaton - UL 1077 Industrial Miniature Circuit Breaker - Supplementary Protector

Product Details

  • Number of Poles
    1 Pole
  • Current Rating
    20 A
  • Trip Curve
    S
  • SCCR
    5 kA
  • UL Standard
    1077
  • UL CCN
    QVNU2
  • UL File No.
    E177451
  • Terminal Type
    Compression
  • Terminal Type
    Standard Terminals
  • Number of Poles
    1
  • Amperage
    20 amperes
  • Number of poles
    Single-pole
  • Trip Type
    13-17X /n
  • Amperage Rating
    20 A
  • Terminals
    Standard
  • Product Weight
    .5 lb
  • Catalog Notes
    Positioned for highly inductive loads especially in control circuits with coils and light filaments.
  • Product Height
    1 in
  • Certifications
    IEC 60947-2 UL 1077 CSA Std. C22.2 No.235
  • Warranty
    1 year
  • Product Width
    .75 in
  • Product Length/Depth
    1 in
  • EAN
    4015082786137
  • Catalog Number
    FAZ-S20/1
  • Product Name
    Eaton FAZ supplementary protector

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

FAZ-S20/1 Related Documents

Datasheet.pdf

Manufacturer warranty

FAZ-S20/1 Eaton
