FAZ-D15/1N Eaton Electronic Components
Part#:FAZ-D15/1N
Manufacturer:Eaton
Product Lifecycle:Active
Get a quick Quote!
Eaton FAZ supplementary protector,UL 1077 Industrial miniature circuit breaker - supplementary protector,High levels of inrush current are expected,15 A,15 kAIC,Single-pole,240 V,10-20X /n,50-60 Hz,Standard terminals,D Curve
About the manufacturer: Eaton is one of the manufacturers that offers Electronic Components that you can order at Powermatic Associates site. At Eaton, we are dedicated to improving quality of life and preserving the environment through power management technologies that emphasize reliability, efficiency, safety, and sustainability. Our attention is on impactful solutions, and we are committed to their success.
Check out the FAZ-D15/1N Eaton price in the box on the right side or send a quick quote.
Product Details
- Number of Poles 1 Pole
- Current Rating 15 A
- Trip Curve D
- SCCR 5 kA
- UL Standard 1077
- UL CCN QVNU2
- UL File No. E177451
- Terminal Type Compression
- Number of poles Single-pole
- Trip Type 10-20X /n
- Catalog Notes Magnetic range for higher startup inrush levels that are usually seen in motors and transformers, and other high inductive systems.
- Amperage Rating 15 A
- Terminals Standard
- Product Weight .5 lb
- Certifications IEC 60947-2 UL 1077 CSA Std. C22.2 No.235
- Product Width 1.5 in
- Warranty 1 year
- Product Height 3 in
- Product Name Eaton FAZ supplementary protector
- EAN 4015082786960
- Catalog Number FAZ-D15/1N
- Product Length/Depth 1.5 in
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
Related documents FAZ-D15/1N Specs
