5369 Eaton Industrial Automation Components

5369 on Powermatic Associates
Eaton

Part#:5369

Manufacturer:Eaton

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

5369 Eaton - Eaton Arrow Hart ultra grip straight blade connector, #16-12 AWG, 20A, Industrial, 125V, Back wire, Black and white, Brass, Nylon, 5-20R, Two-pole, three-wire, grounding, Screw, 0.33-0.66", Nylon, Core pack

Product Details

  • Weight
    .21 pounds
  • Length
    6.5 inches
  • Number of Poles
    2
  • Height
    1.5 inches
  • Amperage
    20 amperes
  • Type:
    Polarized
  • Amps:
    20 A
  • Series:
    0
  • Volts:
    125 VAC
  • Poles:
    2
  • Number of Wires:
    3
  • Ground Type:
    Grounding
  • Cord Size:
    0.25 to 0.69 Inch
  • Material:
    Thermoplastic
  • Constructional Feature:
    Impact Resistant
  • Grade:
    Industrial
  • Approval:
    UL 498
  • Shipping Width:
    2.00 In.
  • Shipping Height:
    3.00 In.
  • Shipping Length:
    2.00 In.
  • Configuration:
    5-20R
  • Color:
    Black
  • Shipping Weight:
    0.15
  • UPC:
    32664390609
  • Packaging type
    Core pack
  • Application
    Industrial
  • Voltage rating
    125V
  • Cord range
    0.33-0.66" in diameter
  • Receptacle type
    Two-pole, three-wire, grounding
  • Design type
    Straight blade
  • Connection type
    Screw
  • Number of wires
    3
  • NEMA configuration
    5-20R
  • Style type
    Straight body
  • Device grade
    Extra heavy-duty industrial specification grade
  • Amperage Rating
    20 A
  • Material
    Nylon
  • Contact material
    Brass
  • Type
    Connector
  • Number Of Poles
    Two-pole
  • Wiring method
    Back wire
  • Face/body material
    Nylon
  • Color
    White
  • Allowable wire size
    #16-12 AWG
  • Device type
    Connector
  • Certifications
    UL NOM Federal Specification Classification 6221 02 cULus Listed
  • Product Weight
    .21 lb
  • Product Width
    3.5 in
  • Product Length/Depth
    6.5 in
  • Product Height
    1.5 in
  • UPC
    032664390609
  • Product Name
    Eaton Arrow Hart ultra grip straight blade connector
  • Catalog Number
    5369

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
