TTR229APSA3D-2.0FL-CTR Banner Safety Light Curtains
Part#:TTR229APSA3D-2.0FL-CTR
Manufacturer:Banner
Alt. Part#:809517
Product Lifecycle:Active
Get a quick Quote!
TTR Series 3 Beam Sensor Array 9.0 in Between Frame; Beam Spacing: 54 mm; Range: 120 mm Diffuse; Output: LO PNP; Input: 18-30 V dc; 2 m (6.5 ft) Flying Leads Endcap D: Flat Up / Round
About the manufacturer: Banner is one of the manufacturers that offers Safety Light Curtains that you can order at Powermatic Associates site. Banner Engineering Corp. is a globally renowned leader in the industrial automation sector. Our diverse product line, comprising sensors, vision sensors, LED lights, indicators, wireless devices, and safety products, caters to businesses of all sizes worldwide.
Check out the TTR229APSA3D-2.0FL-CTR Banner price in the box on the right side or send a quick quote.
Product Details
- Weight 258.54744 g
- Country Of Origin MX
- Min Op. Temperature (°C) -10
- Slot Depth/Array Length (mm) 229
- Number of Pins 4
- Slot Overall Depth (mm) 19
- Max Sensing Range (mm) 120
- IP Rating IP50
- NEMA Rating N/A
- Max Op. Relative Humidity (%) 95% @ 55°C
- Indicator Indicator LEDs
- Beam to Beam Spacing [mm] 54
- Number of Beams 3
- Distance to First Beam [mm] 60.5
- Max Op. Temperature (°C) 55
- Operation Light Operate
- Lens Material Polycarbonate
- Delay at Power-up (ms) 1500
- Adjustments N/A
- Power Supply/Supply Voltage 18-30 V dc
- Output response time (ms) 1
- Quick Disconnect Type No QD
- Outputs PNP
- Connection Cable
- Primary Housing Material Black Anodized Aluminum
- End Cap Type D: Hex Flat Up / Spring 8 mm Round
- Housing Style Roller Conveyor
- Sensing Mode (Detailed) Diffuse
- Cable Length (m) 2
- Power DC
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
TTR229APSA3D-2.0FL-CTR Description
Banner Engineering TTR229APSA3D-2.0FL-CTR is a sensor array designed with a diffuse mode and three beams. This part features a pre-wired connection with a 2m cable and bare end flying leads. It has a rectangular shape with dimensions including a 229mm array length and 54mm beam spacing/pitch. The supply voltage required for operation ranges from 18Vdc to 30Vdc, with a nominal voltage of 24Vdc. It is capable of operating within an ambient air temperature range of -10 to +70°C and offers a degree of protection rated at IP50. This sensor array includes 1 x digital output (PNP transistor), has a sensing distance of 120mm, and utilizes infrared (IR) light with a wavelength of 940 nm.
Related documents TTR229APSA3D-2.0FL-CTR Specs
