SI-QS75C Banner Safety Switches
Part#:SI-QS75C
Alt. Part#:49472
Manufacturer:Banner
Category:Safety Switches
Product Lifecycle:Active
Product description
SI-QS75C INTERLOCK BODY
Product Details
- Weight 123.830616 g
- Country Of Origin DE
- In-Series Diagnostics No
- Mechanical Life (operations in millions) 1
- Coding Level/Tamper Resistance Low
- Auxilliary Output No
- Output Type Contacts
- Connection Type Wiring Chamber
- Feature: Lockable No
- Monitor (Locked) Contacts N/A
- Actuator (Safety) Contacts 1 NC
- SISTEMA B10d = 2 million
- Safety Category Cat 4
- SIL Rating SIL CL 3
- IP Rating IP65
- Min Op. Temperature (°C) -30
- Max Op. Temperature (°C) 80
- PL Rating PL e
- Primary Housing Material Thermoplastic
- Device Type Mechanical - Sensor
- Device Size 75 x 52 x 30
- Switch Style Contact
- Device Shape Rectangular
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of SI-QS75C on Powermatic Associates is $54.00. Order now.
About the product
Banner Engineering SI-QS75C is a tongue-operated door switch from the SI-QS75 series, designed with a Flat-Pak shape for safety machine door, hood, or gate switching applications without actuation. It features a thermoplastic housing and utilizes a wiring chamber connection for installation. This switch is equipped with 1NC contact and supports rated currents of 10A at 24Vac (AC-15), 10A at 110Vac (AC-15), 6A at 230Vac (AC-15), 6A at 24Vdc (DC-13), 1A at 110Vdc (DC-13), and 0.4A at 230Vdc (DC-13). It operates within an ambient air temperature range of -30 to +80°C and offers a degree of protection rated at IP65. The SI-QS75C has a rectangular shape and includes 0 NO auxiliary contacts and 1 NC auxiliary contact.
SI-QS75C Related Documents
Manufacturer warranty
SI-QS75C Banner
$54.00
Your price can be lower.
Log in or Create account to check your discount
Select Qty:
$54.00
$54.00 each
Average response time: 11 minutes
Worldwide Shipping and Delivery
Secure Payment Processing
Warranty
Responsive Customer Support
Got Questions? We've Got Answers!
Need more details?
Feel free to chat with us
Compare SI-QS75C with other products
