OTBVR81 W/Y Banner Sensor Accessories

Banner OTBVR81 W/Y OTB Series: Momentary Action Touch Button w/Yellow F.C.; Input: 20-30 V ac or dc; Upper Housing: Polysulfone; Output: E/M Relay (SPDT); 2 m (6.5 ft) Integral Cable
Banner

Part#:OTBVR81 W/Y

Manufacturer:Banner

Alt. Part#:35086

Product Lifecycle:Active

Get a quick Quote!

OTB Series: Momentary Action Touch Button w/Yellow F.C.; Input: 20-30 V ac or dc; Upper Housing: Polysulfone; Output: E/M Relay (SPDT); 2 m (6.5 ft) Integral Cable

About the manufacturer: Banner is one of the manufacturers that offers Sensor Accessories that you can order at Powermatic Associates site. Banner Engineering Corp. is a globally renowned leader in the industrial automation sector. Our diverse product line, comprising sensors, vision sensors, LED lights, indicators, wireless devices, and safety products, caters to businesses of all sizes worldwide.

Check out the OTBVR81 W/Y Banner price in the box on the right side or send a quick quote.

Product Details

  • Weight
    299.37072 g
  • Country Of Origin
    MX
  • Pro-Editor Compatible (Discrete)
    No
  • Wireless
    No
  • Modbus RTU
    No
  • Feature: Audible
    No
  • IO Link
    No
  • Feature: Hazardous Area
    No
  • Feature: Chemical Resistant
    No
  • Feature: Quick Disconnect
    No
  • Secondary Material
    Thermoplastic
  • Button Operation
    Momentary
  • Primary Housing Color
    Black
  • Min Op. Temperature (°C)
    -20
  • NEMA Type and UL Type Rating
    NEMA 1, 3, 4, 4X, 12, 13
  • Max Op. Temperature (°C)
    50
  • Field Cover Color
    Yellow
  • Max Op. Relative Humidity Non-Condensing (%)
    90% @ 50°C
  • Environmental Rating
    IP66
  • Number of Beams
    1
  • Physical Dimensions (LxWxH or DxH mm)
    59.9 x 43.2 x 48.0
  • Max Output Response Time (ms)
    100
  • Product Size (mm)
    Other
  • Input Type
    AC
  • Output Type
    SPDT e/m Relay
  • Max Input Response Time (ms)
    100
  • Supply Voltage
    20-30 V dc/ac
  • Connection
    Cable
  • Operation
    Normally Open/Normally Closed
  • Number of Input Pins/Conductors
    5
  • Mounting Thread
    M30 x 1.5
  • Primary Housing Material
    Thermoplastic Polysulfone
  • Power
    DC or AC
  • Activation Function
    Optical
  • Power Source
    DC or AC
  • Non-Illuminated
    Yes
  • Sensing Mode (General)
    Single Point Optical
  • Actuation
    Yes
  • Housing Style
    Base Mount - Saddle

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.


OTBVR81 W/Y Description

Banner Engineering OTBVR81 W/Y is a photo-electric optical touch-activated button designed for versatile mounting options, including surface or base flush with a 30mm hole. It operates within an ambient air temperature range of -20°C to +50°C and features a yellow field cover for visibility. This unit is pre-wired with a 2m / 6.5ft 5-wire cable terminated with bare end flying leads, supporting supply voltages of 20Vac-30Vac (24Vac nominal) and 20Vdc-30Vdc (24Vdc nominal). It boasts an IP66 NEMA 1 NEMA 3 NEMA 4 NEMA 4X NEMA 12 NEMA 13 degree of protection, ensuring durability in various environments. The OTBVR81 W/Y has a saddle/yoke-shaped body made from polysulfone upper housing and polypropylene (PP) copolymer field cover with a thermoplastic polyester base, and a black housing color. It offers a momentary NO (Normally Open) or NC (Normally Closed) operating mode with 1 x digital output (SPDT / 1NO/NC relay contact type) for touch activation.



Related documents OTBVR81 W/Y Specs
