M18GRYPQ Banner Indicator Lights

Name: M18GRYPQ
Brand: Banner
Price: 108 USD
Availability: BackOrder

Part#:M18GRYPQ

Alt. Part#:74039

Manufacturer:Banner

Category:Indicator Lights

Product Lifecycle:Active

Product description

EZ-LIGHT: Nickel-Plated Brass Housing M18x1 Threa; 3-Color General Purpose; Green Red Yellow Light; Steady Display; PNP (Sourcing): Encapsulated IP67; M12 Integral QD

Product Details

Weight
72.57472 g
Country Of Origin
US
Pro-Editor Compatible (Discrete)
No
IO Link
No
Modbus RTU
No
Feature: Quick Disconnect
Yes
Feature: Audible
No
Multi-Color Device
Single Color On
Feature: Hazardous Area
No
Feature: Chemical Resistant
No
Wireless
No
Primary Window Material
Thermoplastic Diffused
Min Op. Temperature (°C)
-40
Max Op. Temperature (°C)
50
Physical Dimensions (LxWxH or DxH mm)
16.5 x 70.4
Max Input Response Time (ms)
1
Environmental Rating
IP67
Input Type
PNP
Supply Voltage
10-30 V dc
Number of Input Pins/Conductors
4

Connection

Integral QD

Color Option 2

Red

Color Option 3

Yellow

Animation Option 1

Solid On

Max Current Color (mA)

Quick Disconnect Type

M12 (Euro)

Color Option 1

Green

Color Technology

Standard LED

Product Size (mm)

Color Input Control

Individual (One wire/color, same number of colors as input wires)

Mounting Thread

M18 x 1.0

Number of Colors / Segments

Indication

Yes

Primary Housing Material

Nickel-Plated Brass

Power Source

Power

Housing Style

Barrel Mount - Flat Window

Cable Length (m)

0.15

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of M18GRYPQ on Powermatic Associates is $108.00. Order now.

About the product

Banner Engineering M18GRYPQ is a pilot light from the EZ-LIGHT series designed with a 3-color G/R/Y color pattern LED illumination for clear indication. It features a black housing with a round protruding window and a threaded cylindrical barrel made from nickel-plated brass and a thermoplastic diffused window. This part is equipped with a 4-pin M12 Euro-style QD connector for connectivity and operates on a supply voltage of 10Vdc-30Vdc (12Vdc-24Vdc nom.). It is designed for flush mounting in an 18mm hole with an M18 thread. The indicator has a diameter of 18mm and can operate in ambient air temperatures ranging from -40°C to +50°C. It offers a degree of protection of IP67, consumes 25mA of current, and includes 3 x digital inputs (10-30Vdc; PNP) for color control.
