CSB-M1241DB9 Banner Splitters

CSB-M1241DB9 on Powermatic Associates
Banner
  • CSB-M1241DB9
  • CSB-M1241DB9

Part#:CSB-M1241DB9

Alt. Part#:809381

Manufacturer:Banner

Category:Splitters

Product Lifecycle:Active

Product description

M12 QD Splitter Cable; 4-pin Straight female M12 0.3 m (1 ft) Trunk; 9-pin D-SUB Straight Female M12 2 m (6.56 ft) Branch 1; 2-pin Cable 2 m (6.56 ft) Branch 2; Black Jacket; Nickel-Plated Brass Coupling Nuts

Product Details

  • Weight
    218.177752 g
  • Country Of Origin
    TW
  • Feature: Hazardous Area
    No
  • Oil/Grease Resistant
    No
  • Splitter Function
    Custom
  • Splitter Branches: AWG
    22, 22
  • Splitter Branches: Number of Conductors
    4, 4
  • Splitter Branches Length (m)
    2, 2
  • Splitter Branches: Orientation
    -, Straight
  • Splitter Branches: Coupling Method
    None, DB9 Screw
  • Splitter Cable Diameter
    4.8, 5.2
  • Splitter Branches: Connector Type
    Flying Lead, DB9F
  • Primary AWG
    22
  • Primary Number of Conductors
    4
  • Primary Orientation
    Straight
  • Primary Gender
    Female
  • Primary Connector Type
    EURO
  • Primary Coupling Method
    M12 Single Key
  • Current Rating (A)
    4.0
  • Minimum Temp. (°C)
    -40
  • Maximum Temp. (°C)
    105
  • Voltage Rating (V)
    250 V ac/dc
  • Shield/No Shield
    No Shield
  • Coupling Material/Color
    Nickel Plated Brass
  • Cable Jacket Color
    Black
  • Cordset Length (m)
    2.34
  • Cable Jacket Material
    PVC
  • Trunk Length (m)
    3.05
  • Outside Cable Diameter (mm)
    5.2
  • Connector Body Material/Color
    PUR Black
  • Number of Connectors
    2
  • Number of Contacts
    14

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of CSB-M1241DB9 on Powermatic Associates is $85.00. Order now.

About the product

Euro-style Quick Disconnect Splitter Cable, 4-Pin Straight female Eurofast 0.30 m (1 ft) Trunk, 9-Pin D-SUB Straight Female Eurofast 2m (6.56 ft) Branch 1, 2-Pin Cable 2m (6.56 ft) Branch 2, Nickel Plated Brass Coupling Nuts Black Jacket

CSB-M1241DB9 Related Documents

CSB-M124XDB9-1630955768176.stpCSB-M124XDB9-1630955768173.pdf

Manufacturer warranty

CSB-M1241DB9 Banner

$85.00

Your price can be lower.
Log in or Create account to check your discount

Select Qty:

$85.00

$85.00 each

Average response time: 11 minutes

Worldwide Shipping and Delivery

Secure Payment Processing

Warranty
