WAGO - 891-8992/016-102

WAGO 855-8020 is a component with a short circuit breaking rating, featuring a material weight of 1.1g. It is listed under the commercial data ETIM 8.0 and ETIM 7.0 classifications as EC003015. This part is sold in units of 100 pieces per sales pack unit (SPU), with 10 SPUs per box. It is manufactured in Germany (DE) and comes in box packaging. The product's Global Trade Item Number (GTIN) is 4055143981712, and it has a customs tariff number of 85361010900. The 855-8020 is RoHS compliant without any exemptions, adhering to environmental product compliance standards.

WAGO - 771-9285/016-501

WAGO 831-3625/108-000 is a connector part of the MCS - MULTI CONNECTION SYSTEM, designed without breaking capacity as per DIN EN 61984, indicating it should not be connected or disconnected under load or when live. It adheres to IEC/EN 60664-1 standards, with nominal voltages of 500V (III/3), 630V (III/2), and 1000V (II/2), all with a rated impulse voltage of 6kV. The rated current is 41A, and it has overvoltage category III / Pollution degree 2. UL 1059 approvals include rated voltages of 300V and 600V for Use Groups C and D respectively, with corresponding rated currents of 42A and 5A. CSA approvals mirror these ratings. The connector features a total of 5 potentials, one connection type, and one level, with a 5-pole number. Physical specifications include a pin spacing of 7.62mm, dimensions of 53.7mm in width, 18.8mm in height, 29mm in depth, and a solder pin length of 4mm. It offers variable coding, anti-rotation protection, and mismating protection, with a male connector/plug type for PCB connection, threaded flange locking, and THT PCB contact. The material is light gray Polyamide (PA66) with a flammability class of UL94 V0 and tin-plated electrolytic copper contacts. It weighs 16.1g and operates within a temperature range of -60 to +105°C. The product is RoHS compliant, with a packaging unit of 24 pieces, made in Poland, and has a GTIN of 4066966089981.

WAGO 231-337/108-000 is a connector part of the MCS - MULTI CONNECTION SYSTEM, designed for PCB applications with a male connector/plug type. It operates with a nominal voltage of 320V (III/3 and III/2) and 630V (II/2), rated impulse voltage of 4kV, and a rated current of 12A according to IEC/EN standards. Under UL standards, it has a rated voltage of 300V for Use Group B and D, and 600V according to UL 1977, with a rated current of 10A. CSA standards also recognize this part with a rated voltage of 300V and a rated current of 10A for Use Group B and D. It features a total of 7 potentials, one connection type, and one level, with a pin spacing of 5.08mm. The physical dimensions include a width of 45.56mm, height of 17mm, depth of 8.4mm, and solder pin length of 5mm. It offers variable coding, anti-rotation protection, and is designed for THT PCB contact with a mating direction to the PCB of 90° and a threaded flange for locking. The connector is made from Polyamide (PA66) in orange color, with tin-plated electrolytic copper contacts, and meets UL94 V-0 flammability standards. It operates within a temperature range of -60 to +100°C and is RoHS compliant with exemption 6(c). The product is packaged in boxes of 100 pieces, with a country of origin in Poland and a GTIN of 4050821868736.

WAGO - 891-8993/106-107

WAGO - 891-8993/006-202

WAGO - 771-9994/006-605

WAGO - 713-1436/105-000

WAGO - 805-308/200-604
