1/8 DIN Gasket

Red Lion 716TX is an industrial managed Ethernet switch designed for robust and complex network environments. It supports SNMP v1, v2, and v3 along with Web Browser Management for ease of configuration and monitoring. The switch features N-Ring Technology ensuring a rapid network recovery time of 30ms, N-Link Redundant Ring Technology for enhanced network reliability, and N-View Monitoring Technology for real-time network status. It is equipped with EtherNet/IP CIP Messaging for industrial protocol support and offers IGMP Auto Configuration for efficient multicast traffic management. The 716TX supports 802.1Q tag VLAN, Port VLAN for network segmentation, 802.1p QoS, and Port QoS for traffic prioritization, along with Port Trunking and Port Mirroring for network optimization. It adheres to 802.1d, 802.1w, and 802.1D RSTP for network resilience, features a DHCP Server with Option 82 Relay, Option 61, and IP Fallback for dynamic IP management, and allows Local Port IP Addressing for flexible network configuration. The switch supports 802.1AB-2005 LLDP for device discovery, incorporates MAC Address Based Filtering for port security, and has a configurable alarm output contact. It operates with Normally Open (NO) auxiliary contacts rated for 10-49Vdc (12Vdc / 24Vdc / 48Vdc) and includes 16 x RJ45 ports (10/100BaseTX) for connectivity. The 716TX is designed with ESD + Surge protection on power inputs, housed in a metallic case suitable for DIN rail mounting, and operates within a temperature range of -40 to +70°C. It utilizes Ethernet as its rated insulation voltage (Ui) and is part of the N-Tron 700 series, optimized for demanding industrial environments.

Red Lion PAXC0030 is a dual digital counter designed for flush or door mounting and conforms to the 1/8 DIN size standard, measuring 96mm in width and 48mm in height (3.80" x 1.95"). It features 14.2mm green digits for clear display and operates on a supply voltage range of 85-250Vac, accommodating various standard voltages such as 100Vac, 110Vac, 120Vac, 200Vac, 208Vac, 220Vac, 230Vac, and 240Vac. Part of the PAX series, this counter offers a degree of protection rated at IP65 NEMA 4X, making it suitable for demanding environments. It is equipped with two high-speed digital inputs capable of handling frequencies up to 34kHz for main counting purposes, and an additional three digital inputs (Sink/Source) for user-configured functions.

Red Lion CUB4L010 is a digital counter designed for flush or door mounting with a degree of protection rated at IP65 NEMA 4X, ensuring suitability for various industrial environments. This unit, part of the CUB4L series, features dimensions of W75mm x H39mm (3" x 1.5"), making it compact and easy to integrate into existing systems. It is equipped with 1 x digital input that supports high-speed counters up to 5kHz, capable of both Sink and Source input types. The CUB4L010 operates on a supply voltage range of 9-28Vdc, accommodating both 12Vdc and 24Vdc systems, making it versatile for a wide range of applications.

HMI operator touchscreen panel - for indoor use only - Red Lion (HMIs (Human-Machine Interfaces) HMI G310 series) - 10.4" / 640x480pixels (VGA) TFT touchscreen LCD 32K colors display with backlight + 8-btns. keypad for on-screen menu access - 1 x RJ45 por

Red Lion G310S230 is an HMI / Display unit within the HMI G310 series, designed with a dual Ethernet capability for both indoor and outdoor applications. It features connection options including 2 x RJ45 ports for Ethernet, 2 x RJ11 ports for RS-232, 1 x RJ45 port for RS-422 / RS-485, and 1 x USB type A port for host connections. This unit supports communication protocols such as RS-232, RS-422, RS-485, and Ethernet. It operates on a supply voltage range of 19.2-28.8Vdc, specifically designed for 24Vdc systems. The ambient air temperature range for operation is from 0 to +50°C. It boasts a degree of protection rated at IP66 and NEMA 4X, ensuring durability in various environments. The memory capacity is 32MB (FLASH), and it includes a Compact Flash (CF) slot for storage. The display's brightness is rated at 1000cd/m2, and it is powered by a 32-bit ColdFire CPU.

Red Lion G10C0000 is an HMI / Display unit part of the HMI Rugged Graphite series designed for indoor use. It features an HMI operator touchscreen panel with a connection type that includes 1 x RJ45 port for Ethernet, 2 x RJ11 ports for RS-232, and 1 x RJ45 port for RS-422 / RS-485 communication protocols. The unit operates on a supply voltage of 10-30Vdc, supporting both 12Vdc and 24Vdc, and can function within an ambient air temperature range of -20 to +60 °C. It is protected to a degree of IP66 and NEMA 4X, ensuring its durability in various indoor environments. The G10C0000 offers connection capacity with 7 x module slots and has a power consumption of typically 12 W, with a maximum of 48 W. Its electrical durability is highlighted by a backlight life of 70,000 hours. Additionally, it includes an SD card slot for storage and features a screen brightness of 450cd/m2.

Red Lion GMRTD600, an I/O unit within the I/O modules sub-range, functions as a temperature analog input module. It features a sampling rate for analog inputs ranging from 2.5Hz to 20Hz. This unit is equipped with 6 analog inputs, compatible with Pt100 / Ni120 RTDs, designed to facilitate temperature measurement and monitoring tasks in various applications.

Red Lion SL-8ES-1, part of the Sixnet SL series, is an industrial Ethernet switch designed for automation networks. It features a polycarbonate plastic case and offers connectivity through 8 x RJ45 ports supporting 10/100BaseTX. This switch operates on a supply voltage of 10-30Vdc, accommodating both 12Vdc and 24Vdc systems. It is designed for DIN rail mounting, ensuring easy integration into control panels. The SL-8ES-1 operates within an ambient air temperature range of -40 to +60°C and is rated with an IP30 degree of protection, signifying its resistance to solid objects larger than 2.5mm. It utilizes the Ethernet communication protocol and supports a connection capacity of 8 ports.

Red Lion SN-6921-VZ is a cellular router from the Sixnet IndustrialPro SN 6000 series designed for Verizon 4G/LTE 3G 2G carriers. It features 5 RJ45 ports for Ethernet connections and a DC power input via a screw connector. The router operates on a supply voltage range of 8-30Vdc, accommodating both 12Vdc and 24Vdc systems. It supports Ethernet LTE (4G) communication protocols, making it suitable for a variety of industrial applications requiring robust cellular connectivity.
