Red Lion DSPZR000 is a gateway designed for DIN rail mounting, operating within an ambient air temperature range of 0 to +50 °C. It belongs to the Data Station Plus series and features a high-performance protocol converter and data logger. This part is equipped with a built-in web server that supports HD (1280x720) virtual H.M.I. capabilities. It supports a wide range of communication protocols, including RS-232, RS-422, RS-485, Ethernet, CANopen, DeviceNet, and PROFIBUS, making it versatile for various industrial applications.

Red Lion PAXTM010 is a digital timer from the PAX series, designed with a 1/8 DIN (96x48mm) form factor and features 14.2mm green digits with communication capability. It operates on a supply voltage range of 85-250Vac, accommodating various standard voltages such as 100Vac, 110Vac, 120Vac, 200Vac, 208Vac, 220Vac, 230Vac, and 240Vac. The device is equipped with three digital inputs (Sink/Source) for user input and offers a degree of protection rated at IP65 NEMA 4X, ensuring its suitability for a wide range of industrial applications. Its dimensions are specified as 1/8 DIN horizontal, measuring W96mm x H48mm (3.80" x 1.95").

Red Lion PAXI0020 is a digital counter belonging to the PAX series, designed for dual functionality as either a digital counter or a counter+rate meter. It features a flush or door mounting mode within a 1/8 DIN (96x48mm) form factor, showcasing 14.2mm green digits for clear visibility. The device operates on a supply voltage range of 85-250Vac, accommodating various standard voltages such as 100Vac, 110Vac, 120Vac, 200Vac, 208Vac, 220Vac, 230Vac, and 240Vac. Its dimensions are specified as 1/8 DIN horizontal, measuring W96mm x H48mm (3.80" x 1.95"), and it is protected to a degree of IP65 NEMA 4X. For inputs, it includes 2 high-speed digital inputs capable of up to 34kHz (main inputs) and 3 digital inputs that can function as either Sink or Source (user input). Additionally, it provides 1 analog output for retransmission purposes.

Red Lion PAX2A000 is a universal digital input counter, rate meter, and tachometer designed for flush or door mounting and conforms to the 1/8 DIN (96x48mm) standard, featuring 18mm red/orange/green and 14mm green digits for display. It operates on a wide supply voltage range, accepting both AC (50-250Vac, including 48Vac, 100Vac, 110Vac, 120Vac, 200Vac, 208Vac, 220Vac, 230Vac, 240Vac) and DC (21.6-250Vdc, including 24Vdc, 48Vdc, 60Vdc, 72Vdc, 100Vdc, 110Vdc, 120Vdc, 127Vdc, 200Vdc, 220Vdc, 250Vdc) power sources. This part of the PAX2 series measures 1/8 DIN horizontal (W96mm x H48mm / 3.80" x 1.95") and is protected to IP65 NEMA 4X standards. It includes 2 high-speed counter digital inputs (Sink/Source; 35kHz max) as main inputs and an additional 2 digital inputs (Sink/Source) for user input.

Red Lion PAXCDC20 is a communications unit designed as an extended RS-232 serial communication module card. It features a 9-pin D-Sub connector for establishing connections and utilizes the RS-232 communication protocol to facilitate data exchange.

HMI operator touchscreen panel - for indoor use only - Red Lion (HMIs (Human-Machine Interfaces) HMI G3 Kadet 2 series) - 4" / 480x272pixels TFT touchscreen LCD 32K colors display with backlight - 1 x RJ45 port (Ethernet) + 1 x RJ11 port (RS-232) + 2 x RJ

Red Lion G308C100 is an HMI (Human Machine Interface) / Display unit from the HMI G308 series designed for indoor use. It features a touchscreen panel for operator interaction and supports multiple connection types, including one RJ45 port for Ethernet, two RJ11 ports for RS-232, and one RJ45 port for RS-422 / RS-485 communications. The device operates on a supply voltage range of 19.2-28.8Vdc, specifically designed around a 24Vdc system. It is capable of functioning within an ambient air temperature range of 0 to +50°C. The G308C100 offers a degree of protection rated at IP66 and NEMA 4X, ensuring its durability in various indoor environments. It comes equipped with 32MB of FLASH memory and includes a Compact Flash (CF) slot for storage expansion. The display's brightness is measured at 112cd/m2, and it is powered by a 32-bit ColdFire CPU, facilitating efficient processing and interaction.

Red Lion MPAXI020 is an I/O unit designed as part of the MPAX series I/O modules, featuring a Count/Rate module function. It operates on a supply voltage range of 85-250Vac, accommodating various standard voltages including 100Vac, 110Vac, 120Vac, 200Vac, 208Vac, 220Vac, 230Vac, and 240Vac.

Red Lion PAXT0000 is a universal digital temperature meter part of the PAX series, designed with 3 user inputs and a 1/8 DIN horizontal configuration measuring 96mm in width and 48mm in height (3.80" x 1.95"). It features 14.2mm red digits and has communication capability. This thermometer offers an IP65 NEMA 4X degree of protection and operates on a supply voltage of 11-36Vdc, including 12Vdc and 24Vdc options. It supports a 20Hz analog input sampling rate and includes 1 analog input that accommodates a variety of signals including 4-20mA, 0-20mA, 0-10Vdc, multiple thermocouple types (T, E, J, K, R, S, B, N, C), Pt100, and Ni120 RTDs DC with 16-bits conversion and an accuracy range of 0.12% to 0.7%. Additionally, it features 3 digital inputs (Sink/Source) for user input and 1 analog output for retransmission.

Red Lion PAXLPV00 is a digital tachometer/rate meter from the PAX Lite series, designed to fit a 1/8 DIN (96x48mm) panel cutout. It operates on a supply voltage range of 50-250Vac, including specific voltages such as 48Vac, 100Vac, 110Vac, 120Vac, 200Vac, 208Vac, 220Vac, 230Vac, and 240Vac. This unit features one digital input that supports both sink and source connections. It is built to offer a degree of protection rated at IP65 NEMA 4X, ensuring its suitability for various industrial environments. The dimensions of the PAXLPV00 are standardized to 1/8 DIN horizontal, measuring 96mm in width and 48mm in height (approximately 3.80" x 1.95").
