Ewon by HMS Networks FLB3271_00 is a communications unit from the Flexy cards series, designed as a Wi-Fi modem. This extension card supports 1-11 channels, inclusive of frequencies, and offers security features such as WPA2, WPA, and WEP, compliant with IEEE 802.11 b/g/n standards for Wi-Fi communication. It is a single stream, 802.11 b/g/n Wi-Fi module that includes an LED indicator for operational status. The FLB3271_00 is designed to operate within an ambient air temperature range of -25 to +60 °C.

Ewon by HMS Networks FLB3601_00 is a communications unit categorized under the Flexy cards series, featuring three USB ports designed for extension card functions. Each port is equipped with its own 500mA current limit, while the board maintains a global current limit of 500mA. Port activation allows for all ports to be enabled or disabled simultaneously. The unit's design includes earth GND isolation, which is limited to 500V due to the USB connector design. It is equipped with 4 LED indicators, comprising 3 for port status and 1 for global status. The FLB3601_00 offers connection via 3 USB 2.0 female connectors, supporting pilot up to 10 USB connections. It operates within an ambient air temperature range of -25 to +60°C.

HMS eWon component

Anybus by HMS Networks AB7010-B is a gateway designed for serial communication, belonging to the Serial Communicators sub-range. It functions as a serial communicator/gateway with a configurable RS-232/422/485 interface, supporting produce/consume and query/response ASCII protocols. Capable of handling up to 31 stations with RS485/422, it offers a baud rate range of 1.2-57.6kbit/s. The device supports various Modbus commands, including reading and writing coils, registers, and more, alongside DF1 services such as integrity checks and diagnostics. It features reverse voltage protection, short circuit protection, and galvanic isolation on the sub-network, with an MTTF of over 550,000 hours. Designed for industrial environments, it has immunity to electrostatic discharge, electromagnetic RF fields, fast transients, surge protection, and RF conducted interference, with specific emission levels. The AB7010-B includes 13 configuration switches, 6 LED indicators, and operates on a supply voltage of 21.6-26.4Vdc. It has a plastic housing made of ABS/PC, measures H120mm x W27mm x D75mm, and offers various connection types including 9-pin D-sub and RJ11 connectors. With an IP20 and NEMA 1 degree of protection, it is suitable for DIN rail mounting and operates within an ambient air temperature range of 0 to +55 °C. The device consumes a maximum of 300mA at 24Vdc and is designed for operation in environments with up to 95% relative humidity, non-condensing.

Anybus by HMS Networks AB7647-F is a gateway belonging to the X-gateway series designed for protocol translation. This part functions as a DeviceNet scanner and PROFINET-IO device, featuring vertical or flat installation positions with galvanic isolation on both BUS/Ethernet sides. The I/O configuration is manageable via USB port using Anybus Configuration Manager software. It includes 8 configuration switches and 10 LED indicators for fieldbus, sub-network, and device status monitoring. The supply voltage requirement is 19.2-28.8Vdc, with a nominal 24Vdc. Dimensions are H127mm x W44mm x D114mm, constructed from aluminium and plastic housing. Connection types include 1 x RJ45 LAN connector for 100Mbit/s Ethernet PROFINET I.O. in full duplex, 1 x 5-pin plug-in connector for DeviceNet, 1 x 2-poles 5.08mm plug-in screw connector for power, and 1 x USB connector. It offers an IP20 NEMA 1 degree of protection and is suitable for DIN rail mounting. The communication protocols supported are DeviceNet and PROFINET IO. It operates within an ambient air temperature range of -25 to +65°C, with a current consumption of 400mA (max) and 200mA (typical) at 24Vdc. Storage temperature range is -40 to +85°C. Speed capabilities are 100Mbit/s for PROFINET and 125kbit/s, 250kbit/s, 500kbit/s for DeviceNet. Humidity tolerance is 5-95% relative humidity (RH; non-condensing).
