Schneider Electric LC1F115B5 is a high-power magnetic contactor within the F sub-range, designed for surface mounting. It features ring-lugs/bar connections and operates with 3 poles (3P; 3NO). The contactor is rated for a current of 200A under AC-1 conditions and 115A at 440Vac under AC-3 conditions. The control voltage (AC) required for operation ranges from 20.4-26.4Vac (24Vac nominal; 50Hz; 0.85...1.1 x Uc), and it can handle a rated operating voltage (Ue) of up to 1000 V. This model comes without normally open (NO) or normally closed (NC) auxiliary contacts. It is capable of withstanding a rated impulse voltage (Uimp) of 8 kV and supports rated active power (kW) outputs of 30kW at 220-230Vac, 55kW at 380-400Vac, 59kW at both 415Vac and 440Vac, 75kW at 500Vac, 80kW at 660-690Vac, and 65kW at 1000Vac, all under AC-3 conditions. The LC1F115B5 boasts a mechanical durability of 10 million operations at no load and is designed for phase-to-phase rated voltage (AC) applications up to 1000 V.

Schneider Electric LC1F115F7 is a high-power magnetic contactor within the F sub-range, designed for surface mounting. It features ring-lugs/bar connections and is equipped with 3 poles (3P; 3NO). The contactor is rated for currents of 200A (AC-1) and 115A (440Vac; AC-3), with a control voltage (AC) range of 94-121Vac (110Vac nominal; 40-400Hz; 0.85...1.1 x Uc). The rated operating voltage (Ue) is up to 1000 V, and it has no Normally Open (NO) or Normally Closed (NC) auxiliary contacts. The rated impulse voltage (Uimp) stands at 8 kV. It supports rated active power (kW) of 30kW at 220-230Vac (AC-3), 55kW at 380-400Vac (AC-3), 59kW at both 415Vac and 440Vac (AC-3), 75kW at 500Vac (AC-3), 80kW at 660-690Vac (AC-3), and 65kW at 1000Vac (AC-3). The mechanical durability of the LC1F115F7, at no load, is rated for 10,000,000 operations, and its phase-to-phase rated voltage (AC) is 1000 V.

Schneider Electric LC1F115G7 is a high-power magnetic contactor within the F sub-range, designed for surface mounting. It features a 3-pole (3P; 3NO) configuration with ring-lugs/bar connections. The contactor is rated for currents of 200A (AC-1) and 115A (440Vac; AC-3), and operates with a control voltage (AC) range of 102-132Vac (120Vac nominal; 40-400Hz; 0.85...1.1 x Uc). The rated operating voltage (Ue) is up to 1000 V, with no Normally Open (NO) or Normally Closed (NC) auxiliary contacts. It has a rated impulse voltage (Uimp) of 8 kV and supports rated active power (kW) of 30kW (220-230Vac; AC-3), 55kW (380-400Vac; AC-3), 59kW (415Vac; AC-3), 59kW (440Vac; AC-3), 75kW (500Vac; AC-3), 80kW (660-690Vac; AC-3), and 65kW (1000Vac; AC-3). The mechanical durability of the contactor is rated at 10,000,000 operations at no load, with a phase-to-phase rated voltage (AC) of 1000 V.

Schneider Electric LC1F115U7 is a high-power magnetic contactor within the F sub-range, designed for surface mounting. It features a 3-pole (3P; 3NO) configuration and supports ring-lugs/bar connections. This contactor is rated for currents of 200A under AC-1 conditions and 115A at 440Vac under AC-3 conditions. The control voltage (AC) specifications are 204-264Vac (240Vac nominal; 40-400Hz; 0.85...1.1 x Uc), with a rated operating voltage (Ue) of 1000 V. It has no Normally Open (NO) or Normally Closed (NC) auxiliary contacts. The rated impulse voltage (Uimp) is 8 kV. The rated active power ranges from 30kW at 220-230Vac to 80kW at 660-690Vac under AC-3 conditions, with mechanical durability rated at 10 million operations at no load. The rated voltage (AC) phase-to-phase is 1000 V.

Schneider Electric LC1F185B5 is a high-power magnetic contactor within the F sub-range, designed for surface mounting. It features a 3-pole (3P; 3NO) configuration and supports ring-lugs/bar connections. The contactor is rated for currents of 275A under AC-1 conditions and 185A at 440Vac under AC-3 conditions. It operates with a control voltage (AC) range of 20.4-26.4Vac (24Vac nominal; 50Hz; 0.85...1.1 x Uc) and has a rated operating voltage (Ue) of up to 1000 V. The LC1F185B5 does not include normally open (NO) or normally closed (NC) auxiliary contacts. It is capable of handling rated impulse voltage (Uimp) up to 8 kV and supports rated active power (kW) of 55kW at 220-230Vac, 90kW at 380-400Vac, 100kW at 415Vac and 440Vac, 110kW at 500Vac and 660-690Vac, and 100kW at 1000Vac, all under AC-3 conditions. The mechanical durability of the contactor is rated at 10,000,000 operations at no load, and it is designed for phase-to-phase rated voltage (AC) applications up to 1000 V.

Schneider Electric LC1F185F7 is a high-power magnetic contactor within the F sub-range. It features ring-lugs/bar connections and is designed with 3 poles (3P; 3NO). The rated current for this contactor is 275A under AC-1 conditions and 185A at 440Vac under AC-3 conditions. It is suitable for surface mounting and operates with a control voltage (AC) range of 94-121Vac (110Vac nominal; 40-400Hz; 0.85...1.1 x Uc). The rated operating voltage (Ue) is up to 1000 V, and it does not include normally open (NO) or normally closed (NC) auxiliary contacts. The rated impulse voltage (Uimp) is 8 kV. This contactor can handle rated active power (kW) of 55kW at 220-230Vac, 90kW at 380-400Vac, 100kW at 415Vac and 440Vac, 110kW at 500Vac and 660-690Vac, and 100kW at 1000Vac, all under AC-3 conditions. Its mechanical durability at no load is rated for 10,000,000 operations, and the rated voltage (AC) phase-to-phase is 1000 V.

Schneider Electric M9F12340 is a Miniature Circuit Breaker (MCB) within the C60N sub-range, designed with 3 poles and a rated current of 40A. It operates with a rated voltage of 125Vdc and a phase-to-phase rated voltage of 440V in AC applications. This MCB features a tripping curve D, ensuring precise protection. It is equipped to handle a rated impulse voltage (Uimp) of 6 kV and is designed to protect all 3 poles.

Schneider Electric XAPM1201 is a control station that falls under the XAP sub-range. This part is a die-cast empty control station featuring 1 cut-out, which can be oriented vertically or horizontally. It is constructed from a zinc alloy and has a rectangular shape. The XAPM1201 offers a high degree of protection with ratings of IP69, IP65, and IP69K, making it suitable for various environmental conditions. It is designed for flush mounting and requires a mounting hole with a diameter of 22 mm. The dimensions of the control station are 80 mm in height, 51.5 mm in depth, and 80 mm in width. It can be stored and operated in ambient air temperatures ranging from -40 to +70 degrees Celsius.

Schneider Electric XAPM24 is a die-cast empty control station from the XAP sub-range, designed without openings and constructed from zinc alloy. This square-shaped control station offers a high degree of protection with ratings of IP69, IP65, and IP69K, ensuring its suitability for various environmental conditions. It is intended for flush mounting and has dimensions of 130 mm in height, 77.3 mm in depth, and 80 mm in width. The XAPM24 can be stored and operated in ambient air temperatures ranging from -40 to +70 degrees Celsius.

Schneider Electric XAPM31 is a die-cast empty control station from the XAP sub-range, designed without an opening. It is constructed from zinc alloy with a square shape. This control station offers a high degree of protection with ratings of IP69, IP65, and IP69K, making it suitable for various environmental conditions. It is designed for flush mounting and has dimensions of 175 mm in height, 51.5 mm in depth, and 80 mm in width. The XAPM31 can be stored and operated in ambient air temperatures ranging from -40 to +70 degrees Celsius.
