100A-Blank 6 Inch 3P 240VAC Fusible Switch

Load center accessory, QO, mounting base, 3 phase, 42 spaces, 225A main lugs, OEM, neutral busbar

Square D by Schneider Electric QOM2125VHL is a Miniature Circuit Breaker (MCB) designed for primary or main circuit protection. It features a bolt-on mounting mode and a bolt-on connection type, ensuring secure installation. This MCB is rated for a current of 125A and can accommodate a voltage range of 120V to 240V AC. It is compatible with wire cross-sections from 4AWG to 250kcmil for both aluminum and copper cables, utilizing lug type terminals for connections. The QOM2125VHL is a 2-pole circuit breaker with a short circuit breaking rating of 22kA at 240Vac, designed to provide circuit protection in a variety of applications.

Square D by Schneider Electric HGL36060T is a Moulded Case Circuit Breaker (MCCB) within the PowerPacT HGL sub-range. It features a removable/interchangeable trip unit PowerPacT H-Frame 150 TMD, designed for 3-pole (3P) configurations with a rated current of 60A. This MCCB operates at a rated insulation voltage of 750 V, with AC rated voltages of 600Vac and 600Y/347Vac, and a DC rated voltage of 500Vdc. It offers thermal protection for overload scenarios and magnetic protection for short-circuit conditions. The HGL36060T is designed for individual unit mount on plate, with dimensions of 163 mm in height, 104 mm in width, and 86 mm in depth. It has an IP40 degree of protection and operates via a toggle (manual) mechanism. Protection settings include over-current fixed at 60A, short-circuit hold current fixed at 800A, and short-circuit trip current fixed at 1450A. The rated operating voltage is 690 V, with a rated impulse voltage of 8 kV. The trip current rating is 60 AT, with a frame current rating of 150 AF. Its short-circuit breaking rating varies by voltage, including 65kA at 240Vac, 35kA at 480Vac and 480Y/277Vac, 18kA at 600Vac and 600Y/347Vac, and 20kA at 250Vdc and 500Vdc, all according to UL489 standards. The trip unit type is thermal-magnetic (fixed), with no display, and it falls under utilisation category A. Connections are made via lugs on both load and line sides.

Square D by Schneider Electric HOM120AFIC is a Miniature Circuit Breaker (MCB) with Arc-Fault Circuit Interrupter (AFI) functionality designed for plug-in connection. It features a single pole configuration and is rated for a current of 20A with an operating voltage of 120V AC. The mounting mode for this device is plug-in, accommodating wire cross-sections of 14-8AWG for one aluminum or copper cable and 14-10AWG for two copper cables. It has a short circuit breaking rating of 10kA at 120Vac and utilizes screw clamp type terminals for secure wire connections.

Square D by Schneider Electric HC2692B is a panelboard from the HCN sub-range designed as a type 1 panelboard enclosure. It features dimensions of H2337mm x W660mm (H92" x W26") and supports a rated current range from 225A to 600A. This product is built to offer a degree of protection classified as NEMA 1.

Square D by Schneider Electric HC3273WP is a panelboard from the HCM sub-range designed to serve as a panelboard enclosure with a type 3R/12 rating. It features dimensions of H1854mm x W813mm (H73" x W32") and supports a rated current range from 225A to 800A. This product is engineered to meet NEMA 3R and NEMA 12 degrees of protection, ensuring it is suitable for use in environments requiring these specific protection standards.

WIREWAY 12 x 6 - N12 - 10 ft lg

Timing Relay, Type JCK, plug In, one shot, adjustable time, 0.1 to 10 seconds, 10A, 240 VAC, 24 VAC/DC

Schneider Electric CA2SK20T7 is a control relay with a mechanical durability of 10,000,000 operations at no load. It features a mounting mode that accommodates both plate and DIN rail installations. Designed for use in AC-15 and DC-13 utilisation categories, this part includes two SPST-NO (Single Pole Single Throw - Normally Open) contacts. The CA2SK20T7 is equipped with screw clamp terminals and supports an operating rate of up to 1,200 cycles per hour.
