Vision Sensors on Powermatic Associates

VE Series Mounting Plate; 4 x 3.3 mm, 2 x M8 X 1.25 mm; 3 x 10-32, and 2 x 1/4-20 Mounting Holes

Banner Engineering PPROCAMCQ is a digital industrial vision camera featuring a 1.3 Megapixel resolution. It is designed for C-mount installation and operates within an ambient air temperature range of 0 to +50 degrees Celsius. This camera has a net height of 52 mm, a width of 52 mm, and a depth of 87 mm. It is part of the PROII Sealed series and boasts a washdown-rated PCCC design. The connection is facilitated through a pre-equipped M12 connector. The PPROCAMCQ offers a degree of protection rated at IP68 and IP69K, ensuring its suitability for demanding environments. It operates on a supply voltage range of 10Vdc to 30Vdc, with nominal values of 12Vdc and 24Vdc. The housing is made from nickel-plated aluminium, contributing to its robustness. Communication with this camera is enabled via Modbus TCP and RS-232 protocols.

Banner Engineering PPROCAM1.3 is a digital industrial vision camera featuring a 1.3 Megapixel resolution. It is designed for C-mount installation and operates within an ambient air temperature range of 0 to +50 degrees Celsius. The camera has a net height of 30 mm, a width of 32 mm, and a depth of 78 mm, encapsulated in an aluminium housing for durability. It belongs to the PROII series and is pre-equipped with an M12 connector for connectivity. The PPROCAM1.3 offers a degree of protection rated at IP20 NEMA 1, ensuring it is protected against solid objects larger than 12.5 mm but not against water. It supports a supply voltage range of 10Vdc to 30Vdc, with nominal values of 12Vdc and 24Vdc. Communication with the camera is facilitated through Modbus TCP and RS-232 protocols, allowing for versatile integration into various industrial systems.

Banner Engineering P4O1.3RS is a sensor designed for in-line vision and inspection tasks, featuring a 0.3 Megapixel camera. It is compatible with C-mount mounting mode and operates within an ambient air temperature range of 0 to +50 degrees Celsius. This model, part of the P4 OMNI series, has a net height of 147 mm, a width of 67 mm, and a depth of 34 mm. It is designed as a barcode reader and comes pre-equipped with an RJ45 connector for connectivity. The P4O1.3RS offers a degree of protection rated at IP20 NEMA 1 and requires a supply voltage of 10Vdc to 30Vdc, with 12Vdc and 24Vdc as nominal. The housing is made of black anodized aluminum with a glass lens. For communication, it supports Ethernet, Modbus TCP, and RS-232 protocols. Additionally, it features 4 digital outputs (PNP/NPN transistor).

Banner Engineering P4O1.3R-OC is a sensor designed for right-angle vision or inspection tasks, featuring a 1.3 Megapixel camera. It is part of the P4 OMNI series and is equipped for mounting via a C-mount. This sensor operates within an ambient air temperature range of 0 to +50 degrees Celsius and has a net height of 125 mm, width of 67 mm, and depth of 56 mm. The design follows the PCCC standard, and it connects through a pre-equipped RJ45 connector. With an IP20 degree of protection, it is housed in aluminium, ensuring durability within its specified operating conditions. The P4O1.3R-OC supports a supply voltage range of 10Vdc to 30Vdc, with nominal values at 12Vdc and 24Vdc. Communication is facilitated through Modbus TCP RS-232 protocol, and it features 4 digital outputs (PNP/NPN transistor) for interfacing with other devices or systems.

Banner Engineering P4O1.3I-BD is a sensor from the P4 OMNI series designed for in-line vision or inspection tasks, featuring a 1.3 Megapixel camera. This unit is equipped for C-mount installation and operates within an ambient air temperature range of 0 to +50°C. It has a net height of 147 mm, a width of 67 mm, and a depth of 34 mm, encased in an aluminium housing for durability. The sensor is pre-equipped with an RJ45 connector for connectivity and supports Modbus TCP RS-232 communication protocol. It offers a degree of protection rated at IP20 and requires a supply voltage of 10Vdc to 30Vdc, with 12Vdc and 24Vdc as nominal values. Additionally, it features 4 x digital outputs (PNP/NPN transistor) for interfacing with other devices.

Banner Engineering PPROCAMQ is a digital industrial vision camera featuring a 0.3 Megapixel resolution and designed for mounting via a C-mount. It operates within an ambient air temperature range of 0 to +50 °C and has dimensions of 52 mm in height, 52 mm in width, and 87 mm in depth. This model, part of the PROII Sealed series, does not include a lens cover but is washdown rated with a PCCC design. It offers a high degree of protection with ratings of IP68 and IP69K, ensuring durability in harsh environments. The camera is housed in nickel-plated aluminum for added resilience. Connection is facilitated through a pre-equipped M12 connector, and it supports a supply voltage range of 10Vdc to 30Vdc, with nominal values of 12Vdc and 24Vdc. Communication with this device is enabled via Modbus TCP and RS-232 protocols.

Banner Engineering P4O1.3RS-BD is a sensor designed for right-angle vision or inspection tasks, featuring a 1.3 Megapixel camera compatible with C-mount lenses. It operates within an ambient air temperature range of 0 to +50 degrees Celsius and has dimensions of 130 mm in height, 70 mm in width, and 52 mm in depth. This model is part of the P4 OMNI Sealed series, offering an IP68 degree of protection, making it suitable for demanding environments. It is powered by a supply voltage ranging from 10Vdc to 30Vdc, with 12Vdc and 24Vdc as nominal values. The housing is made from nickel-plated aluminum, ensuring durability. For connectivity, it comes pre-equipped with an 8-pin Euro-style M12 female connector and supports Modbus TCP and RS-232 communication protocols. Additionally, it features 4 digital outputs (PNP/NPN transistor) and can store up to 999 inspection configurations (PCCC).

Banner Engineering P4O1.3R-BC is a sensor designed for right-angle vision and inspection tasks, featuring a 1.3 Megapixel camera. It is equipped for C-mount installation and operates within an ambient air temperature range of 0 to +50°C. This model has a net height of 130 mm, a width of 70 mm, and a depth of 52 mm. It is part of the P4 OMNI Sealed series, offering a degree of protection rated at IP68, making it suitable for demanding environments. The sensor's housing is made from nickel-plated aluminium, ensuring durability. It connects via an 8-pin Euro-style M12 female connector and supports Modbus TCP RS-232 communication protocol. The P4O1.3R-BC operates on a supply voltage of 10Vdc to 30Vdc, with 12Vdc and 24Vdc as nominal values, and includes 4 digital outputs (PNP/NPN transistor) for versatile application integration.

Banner Engineering P4CORS is a sensor belonging to the P4 OMNI series, designed primarily for in-line vision and inspection tasks with a 1.3Mpixel camera. It features a C-mount mounting mode and operates within an ambient air temperature range of 0 to +50 °C. The sensor has a net height of 147 mm, a width of 67 mm, and a depth of 34 mm, encased in an aluminium housing for durability. It is pre-equipped with an RJ45 connector for connectivity and supports Modbus TCP RS-232 communication protocol. The P4CORS offers a degree of protection rated at IP20 and requires a supply voltage of 10Vdc to 30Vdc, with 12Vdc and 24Vdc as nominal values. Additionally, it includes 4 x digital outputs (PNP/NPN transistor) for interfacing with other devices.
