Manual Motor Controller 10A, 2 Pole, 277V AC, C Trip, UL508
19 in stock
24 hours
WAGO 714-132 is a male connector/plug designed for PCB connections with a total of 2 potentials and 1 connection type across 1 level. It features a pole number of 2, with a pin spacing of 3.5mm and dimensions of 8.4mm in width, 13.1mm in height, 9.7mm height from the surface, and 6.9mm in depth. The solder pin length is 3.4mm with dimensions of 0.8 x 0.8mm, and it requires a drilled hole diameter with tolerance of 1.2 (+0.1)mm. This part offers variable coding, anti-rotation protection, and is designed for a 90° mating direction to the PCB. It supports a THT PCB contact type with an in-line solder pin arrangement and one solder pin per potential. The connector is black, made from Polyphthalamide (PPA GF) with a flammability class of UL94 V0, and uses Electrolytic Copper (ECu) for the contact material with a tin plating. It has a fire load of 0.012MJ and weighs 0.5g. The operational temperature range is -60 to +100°C, with a processing temperature range of -35 to +60°C. It is RoHS compliant without exemptions, packaged in boxes of 200 pieces, and has a GTIN of 4045454857684. The product is manufactured in Germany and falls under the customs tariff number 85366930000. Its electrical specifications include a nominal voltage of 160V to 320V, a rated impulse voltage of 2.5kV, and a rated current of 8A, with specific ratings per IEC/EN 60664-1 and UL 1059 for certain applications.
290 in stock
24 hours
Wago 221-2401 is a connector designed for in-line splicing with levers, utilizing CAGE-CLAMP spring connections for secure and durable connectivity. It supports a rated current of 32A according to IEC standards and 20A as per UL standards. The connector is suitable for supply voltages up to 450V in IEC applications and up to 600V for UL applications. It operates efficiently within an ambient air temperature range of -60°C to +105°C and maintains its integrity during storage in similar temperature conditions. The 221-2401 is compatible with a wide range of conductor sizes, accommodating 0.34mm² to 4mm² fine stranded conductors, 0.2mm² to 2.5mm² stranded conductors, and 0.2mm² to 4mm² solid conductors, as well as #18AWG to #12AWG fine stranded or stranded conductors and #20AWG to #12AWG solid conductors. Its transparent housing and orange lever facilitate easy inspection and operation, while the polycarbonate material ensures durability.
259 in stock
24 hours
Wago 2004-1201 is a feed-through terminal block designed for push-in CAGE CLAMP spring connections. It supports a rated current of 32A (IEC), 41A (IEC), 30A (UL), 30A (CSA), and 30A (Ex e II). This 1-deck terminal features side and center marking slots and is suitable for Ex e II applications. It has a net height of 8 kV for impulse voltage, a width for 1 feed-through pole (1P), and is compatible with DIN-35 rail mounting. The terminal block is designed for 0.5mm² to 6mm² fine stranded or solid conductors and #20AWG to #10AWG fine stranded or solid conductors, with a 4mm² nominal cross-section. Made from Polyamide (PA) 66, it includes 2-wire connections (1 push-in + 1 push-in) for normally closed (NC) auxiliary contacts. The dimensions are H52.3mm x W6.2mm x D32.9mm, and it operates at a diameter of 800 V (IEC), 600 V (UL/CSA), and 550 V (Ex e II). It is part of the TOPJOB S series.
132 in stock
24 hours
Wago 769-435 is a mounting accessory designed as a coding pin for coding female plugs within the X-COM series. It features an orange color coding for easy identification.
10 in stock
24 hours
Wago 769-411 is a strain relief plate designed with a pin spacing of 5mm, suitable for 2 to 3 poles (2P-3P) configurations. It is part of the X-COM series and features a gray color. This component is specifically crafted to provide strain relief in various applications.
11 in stock
24 hours
Wago 2004-553 is a modular connector designed for jumper contact slot applications, featuring push-in CAGE CLAMP spring connections. It supports a rated current of 32A and is compatible with 0.5mm2 to 6mm2 stranded conductors, as well as 0.5mm2 to 6mm2 solid conductors, including #20AWG to #10AWG sizes for both stranded or solid types. This connector is part of the TOPJOB S series, constructed from Polyamide (PA) 66, ensuring compatibility with a control voltage that is plug-in. The net height and width are specified for 3-poles (3P) configurations, with a net height corresponding to an IEC rating of 6 kV and a diameter rated at IEC 500 V. The dimensions include a residual current sensitivity of W18.6mm, indicating its physical size and installation requirements.
3 in stock
24 hours
Wago 2004-511 is a modular connector designed for push-in CAGE CLAMP spring connections. It supports a rated current of 32A and is part of the TOPJOB S series. This connector is suitable for a 4mm2 conductor size and features a net height compliant with an IEC 6 kV rating. The net width is specified as 1-pole (1P), and it has a power consumption color coded as gray. The residual current sensitivity is marked as W6.2mm. Constructed from Polyamide (PA) 66, it is designed to withstand a diameter rating in accordance with IEC 500 V standards.
7 in stock
24 hours
Wago 734-328 is a strain relief plate designed for use with the X-COM series. It features dimensions of H1.87mm x W12.5mm x D22mm. The color of the part is gray, indicating its design specification for visual identification in system setups.
3 in stock
24 hours
Schneider Electric LC1DT25BL is a magnetic contactor within the Deca sub-range, featuring a low-consumption coil that operates below 2.4W. This contactor is designed with screw connections and has a 4-pole (4NO) configuration. It is rated for a current of 25A under AC-1 conditions and is suitable for DIN rail mounting. The LC1DT25BL offers an IP20 degree of protection and operates with a control voltage range of 19.2-30Vdc, with a nominal 24Vdc. Its rated operating voltage (Ue) reaches up to 690 V, and it includes 1 Normally Open (NO) and 1 Normally Closed (NC) auxiliary contacts, both of the instantaneous type (1NO+1NC). The contactor is capable of withstanding rated impulse voltages up to 6 kV and has a mechanical durability of 15 million operations at no load. The rated voltage for phase-to-phase connections is 690 V, and the power consumption is specified at 2.4 W.
1 in stock
24 hours
Item | Manufacturer | Price | Stock | Delivery | |
---|---|---|---|---|---|
2C10UM Manual Motor Controller 10A, 2 Pole, 277V AC, C Trip, UL508 | Altech Corp. | $49.11 | 19 in stock | 24 hours | |
714-132 WAGO 714-132 is a male connector/plug designed for PCB connections with a total of 2 potentials and 1 connection type across 1 level. It features a pole number of 2, with a pin spacing of 3.5mm and dimensions of 8.4mm in width, 13.1mm in height, 9.7mm height from the surface, and 6.9mm in depth. The solder pin length is 3.4mm with dimensions of 0.8 x 0.8mm, and it requires a drilled hole diameter with tolerance of 1.2 (+0.1)mm. This part offers variable coding, anti-rotation protection, and is designed for a 90° mating direction to the PCB. It supports a THT PCB contact type with an in-line solder pin arrangement and one solder pin per potential. The connector is black, made from Polyphthalamide (PPA GF) with a flammability class of UL94 V0, and uses Electrolytic Copper (ECu) for the contact material with a tin plating. It has a fire load of 0.012MJ and weighs 0.5g. The operational temperature range is -60 to +100°C, with a processing temperature range of -35 to +60°C. It is RoHS compliant without exemptions, packaged in boxes of 200 pieces, and has a GTIN of 4045454857684. The product is manufactured in Germany and falls under the customs tariff number 85366930000. Its electrical specifications include a nominal voltage of 160V to 320V, a rated impulse voltage of 2.5kV, and a rated current of 8A, with specific ratings per IEC/EN 60664-1 and UL 1059 for certain applications. | WAGO | $0.79 | 290 in stock | 24 hours | |
221-2401 Wago 221-2401 is a connector designed for in-line splicing with levers, utilizing CAGE-CLAMP spring connections for secure and durable connectivity. It supports a rated current of 32A according to IEC standards and 20A as per UL standards. The connector is suitable for supply voltages up to 450V in IEC applications and up to 600V for UL applications. It operates efficiently within an ambient air temperature range of -60°C to +105°C and maintains its integrity during storage in similar temperature conditions. The 221-2401 is compatible with a wide range of conductor sizes, accommodating 0.34mm² to 4mm² fine stranded conductors, 0.2mm² to 2.5mm² stranded conductors, and 0.2mm² to 4mm² solid conductors, as well as #18AWG to #12AWG fine stranded or stranded conductors and #20AWG to #12AWG solid conductors. Its transparent housing and orange lever facilitate easy inspection and operation, while the polycarbonate material ensures durability. | WAGO | $0.38 | 259 in stock | 24 hours | |
2004-1201 Wago 2004-1201 is a feed-through terminal block designed for push-in CAGE CLAMP spring connections. It supports a rated current of 32A (IEC), 41A (IEC), 30A (UL), 30A (CSA), and 30A (Ex e II). This 1-deck terminal features side and center marking slots and is suitable for Ex e II applications. It has a net height of 8 kV for impulse voltage, a width for 1 feed-through pole (1P), and is compatible with DIN-35 rail mounting. The terminal block is designed for 0.5mm² to 6mm² fine stranded or solid conductors and #20AWG to #10AWG fine stranded or solid conductors, with a 4mm² nominal cross-section. Made from Polyamide (PA) 66, it includes 2-wire connections (1 push-in + 1 push-in) for normally closed (NC) auxiliary contacts. The dimensions are H52.3mm x W6.2mm x D32.9mm, and it operates at a diameter of 800 V (IEC), 600 V (UL/CSA), and 550 V (Ex e II). It is part of the TOPJOB S series. | WAGO | $1.94 | 132 in stock | 24 hours | |
769-435 Wago 769-435 is a mounting accessory designed as a coding pin for coding female plugs within the X-COM series. It features an orange color coding for easy identification. | WAGO | $0.14 | 10 in stock | 24 hours | |
769-411 Wago 769-411 is a strain relief plate designed with a pin spacing of 5mm, suitable for 2 to 3 poles (2P-3P) configurations. It is part of the X-COM series and features a gray color. This component is specifically crafted to provide strain relief in various applications. | WAGO | $0.71 | 11 in stock | 24 hours | |
2004-553 Wago 2004-553 is a modular connector designed for jumper contact slot applications, featuring push-in CAGE CLAMP spring connections. It supports a rated current of 32A and is compatible with 0.5mm2 to 6mm2 stranded conductors, as well as 0.5mm2 to 6mm2 solid conductors, including #20AWG to #10AWG sizes for both stranded or solid types. This connector is part of the TOPJOB S series, constructed from Polyamide (PA) 66, ensuring compatibility with a control voltage that is plug-in. The net height and width are specified for 3-poles (3P) configurations, with a net height corresponding to an IEC rating of 6 kV and a diameter rated at IEC 500 V. The dimensions include a residual current sensitivity of W18.6mm, indicating its physical size and installation requirements. | WAGO | $11.21 | 3 in stock | 24 hours | |
2004-511 Wago 2004-511 is a modular connector designed for push-in CAGE CLAMP spring connections. It supports a rated current of 32A and is part of the TOPJOB S series. This connector is suitable for a 4mm2 conductor size and features a net height compliant with an IEC 6 kV rating. The net width is specified as 1-pole (1P), and it has a power consumption color coded as gray. The residual current sensitivity is marked as W6.2mm. Constructed from Polyamide (PA) 66, it is designed to withstand a diameter rating in accordance with IEC 500 V standards. | WAGO | $3.74 | 7 in stock | 24 hours | |
734-328 Wago 734-328 is a strain relief plate designed for use with the X-COM series. It features dimensions of H1.87mm x W12.5mm x D22mm. The color of the part is gray, indicating its design specification for visual identification in system setups. | WAGO | $0.55 | 3 in stock | 24 hours | |
LC1DT25BL Schneider Electric LC1DT25BL is a magnetic contactor within the Deca sub-range, featuring a low-consumption coil that operates below 2.4W. This contactor is designed with screw connections and has a 4-pole (4NO) configuration. It is rated for a current of 25A under AC-1 conditions and is suitable for DIN rail mounting. The LC1DT25BL offers an IP20 degree of protection and operates with a control voltage range of 19.2-30Vdc, with a nominal 24Vdc. Its rated operating voltage (Ue) reaches up to 690 V, and it includes 1 Normally Open (NO) and 1 Normally Closed (NC) auxiliary contacts, both of the instantaneous type (1NO+1NC). The contactor is capable of withstanding rated impulse voltages up to 6 kV and has a mechanical durability of 15 million operations at no load. The rated voltage for phase-to-phase connections is 690 V, and the power consumption is specified at 2.4 W. | Schneider Electric | $166.00 | 1 in stock | 24 hours |
