Contactors

Schneider Electric LC1D126GD is a magnetic contactor from the Deca sub-range designed for efficient circuit control. It features ring-lugs connections and operates with 3 poles (3P; 3NO). The contactor is rated for currents of 25A (AC-1) and 12A (440Vac; AC-3), and it can be mounted on a DIN rail. With a net width of 45 mm and an IP20 degree of protection, it ensures compatibility with various setups. The control voltage (DC) ranges from 94-156Vdc (125Vdc nominal; 0.75...1.25 x Uc), and it can handle a rated operating voltage (Ue) up to 690 V. It includes 1 normally open (NO) auxiliary contact and 1 normally closed (NC) auxiliary contact, both of the instantaneous type (1NO+1NC). The rated impulse voltage (Uimp) is 6 kV. Its rated active power capacity spans from 3kW at 220-230Vac to 7.5kW at 660-690Vac in AC-3 category. The rated power in horsepower (HP) varies from 0.5HP at 115Vac in single-phase to 10HP at 575-600Vac in three-phase, under UL/CSA standards. The mechanical durability of the LC1D126GD is rated at 15 million operations at no load, and its electrical durability with load is 2 million operations. The rated voltage (AC) phase-to-phase is 690 V.

Schneider Electric LC1D09PD is a magnetic contactor from the Deca sub-range, designed with screw connections and three poles (3P; 3NO). It has a rated current of 25A (AC-1) and 9A (440Vac; AC-3), with a mounting mode suitable for DIN rail installation. The net width of the contactor is 45 mm, and it offers a degree of protection rated at IP20. The control voltage (DC) ranges from 117-193Vdc, with a nominal value of 155Vdc. This contactor is capable of operating at a rated voltage (Ue) of up to 690 V and includes 1 normally open (NO) auxiliary contact. The rated impulse voltage (Uimp) is 6 kV, and it supports rated active power ranging from 2.2kW to 5.5kW across various AC voltages. It also features 1 normally closed (NC) auxiliary contact with instantaneous contact types of 1NO+1NC. The rated power in horsepower (HP) varies from 0.33HP to 7.5HP across different voltages and phases, according to UL/CSA standards. The mechanical durability of the LC1D09PD is rated at 15 million operations at no load, and its electrical durability with load is 2 million operations. The rated voltage (AC) phase-to-phase is 690 V.

Schneider Electric LC1D09J7 is a magnetic contactor from the Deca sub-range, featuring screw connections and designed with 3 poles (3P; 3NO). It has a rated current of 25A (AC-1) and 9A (440Vac; AC-3), with a mounting mode suitable for DIN rail installation. The net width of the contactor is 45 mm, and it offers a degree of protection rated at IP20. The control voltage (AC) ranges from 9.6-13.2Vac (12Vac nominal; 50Hz; 0.8...1.1 x Uc) to 10.2-13.2Vac (12Vac nominal; 60Hz; 0.85...1.1 x Uc), with a rated operating voltage (Ue) of up to 690 V. It includes 1 Normally Open (NO) auxiliary contact and 1 Normally Closed (NC) auxiliary contact, both of the instantaneous type (1NO+1NC). The rated impulse voltage (Uimp) is 6 kV. Its rated active power ranges from 2.2kW at 220-230Vac to 5.5kW at 660-690Vac (all AC-3), and the rated power (HP) varies from 0.33HP at 115Vac to 7.5HP at 575-600Vac, accommodating various single-phase and 3-phase applications under UL/CSA standards. The mechanical durability of the LC1D09J7 is rated at 15 million operations at no load, and its electrical durability is rated at 2 million operations with load. The rated voltage (AC) for phase-to-phase applications is 690 V.

Schneider Electric LC1D098JD is a magnetic contactor within the Deca sub-range, featuring screw connections and designed with 4 poles (2NO+2NC). It has a rated current of 20A under AC-1 conditions and is suitable for DIN rail mounting. The dimensions include a net width of 45 mm, and it offers a degree of protection rated at IP20. This contactor operates with a control voltage (DC) range of 9-15Vdc, with a nominal value of 12Vdc, and can handle a rated operating voltage (Ue) up to 690 V. It includes 1 Normally Open (NO) and 1 Normally Closed (NC) auxiliary contact, both rated for instantaneous operation. The contacts type is specified as 1NO+1NC instantaneous aux. It boasts a mechanical durability of 15,000,000 operations at no load and can withstand a rated impulse voltage (Uimp) of 6 kV. The rated voltage for phase-to-phase connections is specified at 690 V.

Schneider Electric LC1D096EL is a magnetic contactor from the Deca sub-range, featuring a low-consumption coil design and ring-lugs connections. This 3-pole (3P; 3NO) contactor has a rated current of 25A for AC-1 and 9A for 440Vac in AC-3 conditions. It is designed for DIN rail mounting and has a net width of 45 mm. The LC1D096EL offers a degree of protection rated at IP20 and operates with a control voltage (DC) range of 38.4-60Vdc, nominally at 48Vdc. Its rated operating voltage (Ue) reaches up to 690 V, and it includes 1 normally open (NO) auxiliary contact. The rated impulse voltage (Uimp) is 6 kV, and it can handle rated active power ranging from 2.2kW at 220-230Vac to 5.5kW at 660-690Vac in AC-3 conditions. Additionally, it features 1 normally closed (NC) auxiliary contact and instantaneous auxiliary contacts type of 1NO+1NC. The rated power in horsepower (HP) varies from 0.33HP at 115Vac in single-phase to 7.5HP at 575-600Vac in 3-phase conditions, according to UL/CSA standards. Its mechanical durability is rated at 15 million operations at no load, and its electrical durability with load is 2 million operations. The rated voltage (AC) phase-to-phase is 690 V, and it has a power consumption of 2.4 W.

Schneider Electric LC1D096E7 is a magnetic contactor from the Deca sub-range, designed for ring-lugs connections. It features 3 poles (3P; 3NO) and is rated for currents of 25A (AC-1) and 9A (440Vac; AC-3). This contactor is suitable for DIN rail mounting and has a net width of 45 mm. It offers a degree of protection of IP20 and operates within control voltage ranges of 38.4-52.8Vac (48Vac nominal; 50Hz; 0.8...1.1 x Uc) and 40.8-52.8Vac (48Vac nominal; 60Hz; 0.85...1.1 x Uc). The rated operating voltage (Ue) is up to 690 V, and it includes 1 normally open (NO) auxiliary contact. The rated impulse voltage (Uimp) is 6 kV. Its rated active power spans from 2.2kW at 220-230Vac to 5.5kW at 660-690Vac (AC-3). It also features 1 normally closed (NC) auxiliary contact and instantaneous auxiliary contacts type of 1NO+1NC. The rated power in horsepower (HP) ranges from 0.33HP at 115Vac to 7.5HP at 575-600Vac, under various conditions as specified. The mechanical durability of the LC1D096E7 is rated at 15 million operations at no load, and its electrical durability with load is 2 million operations. The rated voltage (AC) for phase-to-phase connections is 690 V.

Schneider Electric LC1D093R7 is a magnetic contactor from the Deca sub-range, featuring spring connections and designed with 3 poles (3P; 3NO). It has a rated current of 16A (AC-1) and 9A (440Vac; AC-3), with a mounting mode suitable for DIN rail installation. The net width of the contactor is 45 mm, and it offers a degree of protection rated at IP20. The control voltage (AC) ranges from 352-484Vac (440Vac nom.; 50Hz; 0.8...1.1 x Uc) to 374-484Vac (440Vac nom.; 60Hz; 0.85...1.1 x Uc), with a rated operating voltage (Ue) of 690 V. It includes 1 Normally Open (NO) auxiliary contact and 1 Normally Closed (NC) auxiliary contact, both of the instantaneous type (1NO+1NC). The rated impulse voltage (Uimp) is 6 kV. Rated active power spans from 2.2kW (220-230Vac; AC-3) to 5.5kW (660-690Vac; AC-3), and the rated power (HP) ranges from 0.33HP (115Vac; single-phase; 50Hz/60Hz; UL/CSA) to 7.5HP (575-600Vac; 3-phase; 50Hz/60Hz; UL/CSA). Mechanical durability is specified at 15 million operations at no load, and electrical durability at 2 million operations with load. The rated voltage (AC) for phase-to-phase is 690 V.

Schneider Electric LC1BP33M31 is a bar-mounted magnetic contactor within the B sub-range. It features ring-lugs/bar connections and is designed with 3 poles (3P; 3NO). The contactor has a rated current of 2000A for AC-1 applications and 1500A for 440Vac AC-3 applications. The control voltage (AC) specification is 187-242Vac (220Vac nominal; 50Hz-400Hz; 0.85...1.1 x Uc), and the rated operating voltage (Ue) is 1000 V. It includes 3 Normally Open (NO) auxiliary contacts and 1 Normally Closed (NC) auxiliary contact. The rated active power varies with voltage, offering 425kW at 220-230Vac, 750kW at 380-400Vac, 800kW at 415Vac and 440Vac, 700kW at 500Vac, 750kW at 660-690Vac, and 670kW at 1000Vac, all under AC-3 conditions. The mechanical durability of the LC1BP33M31, at no load, is rated at 1,200,000 operations. The rated voltage (AC) for phase-to-phase connections is 1000 V.

Schneider Electric LC1DT60A6BD is a magnetic contactor from the Deca sub-range, featuring an EverLink(TM) terminal design for ring-lugs connections. This 4-pole (4P; 4NO) contactor is designed to handle a rated current of 60A (AC-1) and can be mounted on a DIN rail. It has a net width of 70 mm and offers a degree of protection rated at IP20. The control voltage for this unit is DC, ranging from 18-30Vdc with a nominal voltage of 24Vdc (0.75...1.25 x Uc). It includes 1 Normally Open (NO) and 1 Normally Closed (NC) auxiliary contact, both of the instantaneous type (1NO+1NC). The LC1DT60A6BD is capable of withstanding a rated impulse voltage (Uimp) of 6 kV and has a mechanical durability of 6 million operations at no load. It is designed to operate at a rated voltage (AC) of up to 690 V phase-to-phase.

Schneider Electric LC1DT60A3V7 is a magnetic contactor from the Deca sub-range, featuring EverLink(TM) terminal design for secure connections. It is equipped with spring connections for control and screw connections for power, ensuring a robust connection system. This 4-pole (4NO) contactor is designed to handle a rated current of 60A (AC-1) and can be mounted on a DIN rail. With a net width of 70 mm and an IP20 degree of protection, it is compact and offers basic protection against touch. The control voltage ranges from 320-440Vac at 50Hz and 340-440Vac at 60Hz, with a nominal voltage of 400Vac. It includes 1 Normally Open (NO) and 1 Normally Closed (NC) auxiliary contacts, both rated for instantaneous operation. The contactor is capable of withstanding a rated impulse voltage (Uimp) of 6 kV and has a mechanical durability of 6 million operations at no load. The rated voltage for phase-to-phase connections is up to 690 V.
