Contactors

Schneider Electric LC1D323R7 is a magnetic contactor from the Deca sub-range, featuring spring connections and designed with 3 poles (3P; 3NO). It has a rated current of 50A for AC-1 and 32A for AC-3 at 440Vac. This contactor is suitable for DIN rail mounting and has a net width of 45 mm. It offers a degree of protection rated at IP20 and operates with a control voltage (AC) range of 352-484Vac at 50Hz and 374-484Vac at 60Hz, with a nominal voltage of 440Vac. The rated operating voltage (Ue) is up to 690 V, and it includes 1 normally open (NO) auxiliary contact. The rated impulse voltage (Uimp) is 6 kV. Its rated active power reaches up to 18.5kW for AC-3 across various voltages, and it also features 1 normally closed (NC) auxiliary contact with a contact type of 1NO+1NC instantaneous aux. The rated power in horsepower (HP) varies from 2HP at 115Vac to 25HP at 575-600Vac, accommodating both single-phase and 3-phase connections. The mechanical durability of the LC1D323R7 is rated at 15 million operations, and its electrical durability with load is 1.6 million operations. The rated voltage for phase-to-phase connections is 690 V.

Schneider Electric LC1D323JD is a magnetic contactor from the Deca sub-range, featuring spring connections and designed with 3 poles (3P; 3NO). It has a rated current of 50A (AC-1) and 32A (440Vac; AC-3), with a mounting mode suitable for DIN rail installation. The net width of the contactor is 45 mm, and it offers a degree of protection rated at IP20. The control voltage (DC) ranges from 9-15Vdc (12Vdc nominal; 0.75...1.25 x Uc), and the rated operating voltage (Ue) is up to 690 V. This contactor includes 1 normally open (NO) auxiliary contact and 1 normally closed (NC) auxiliary contact, both of the instantaneous type (1NO+1NC). The rated impulse voltage (Uimp) is 6 kV. It supports rated active power of 7.5kW (220-230Vac; AC-3) up to 18.5kW (660-690Vac; AC-3), and rated power (HP) ranges from 2HP (115Vac; single-phase; 50Hz/60Hz; UL/CSA) to 25HP (575-600Vac; 3-phase; 50Hz/60Hz; UL/CSA). The mechanical durability of the LC1D323JD is up to 15,000,000 operations, and its electrical durability (with load) reaches 1,600,000 operations. The rated voltage (AC) for phase-to-phase connections is 690 V.

Schneider Electric LC1D256Q7 is a magnetic contactor from the Deca sub-range, designed for ring-lugs connections. It features 3 poles (3P; 3NO) and is rated for currents of 40A (AC-1) and 25A (440Vac; AC-3). This contactor is suitable for DIN rail mounting and has a net width of 45 mm. It offers a degree of protection of IP20 and operates with a control voltage (AC) range of 304-418Vac (380Vac nominal; 50Hz; 0.8...1.1 x Uc) and 323-418Vac (380Vac nominal; 60Hz; 0.85...1.1 x Uc). The rated operating voltage (Ue) is 690 V, and it includes 1 normally open (NO) auxiliary contact and 1 normally closed (NC) auxiliary contact, both of the 1NO+1NC instantaneous type. The rated impulse voltage (Uimp) is 6 kV. Its rated active power (kW) spans from 5.5kW at 220-230Vac to 15kW at 660-690Vac in AC-3 category. The rated power (HP) ranges from 2HP at 115Vac to 20HP at 575-600Vac, covering various configurations under UL/CSA standards. The mechanical durability of the LC1D256Q7 is rated at 15 million operations at no load, and its electrical durability is rated at 1.6 million operations with load. The rated voltage (AC) for phase-to-phase connections is 690 V.

Schneider Electric LC1D256E7 is a magnetic contactor from the Deca sub-range, designed with ring-lugs connections and three poles (3P; 3NO). It has a rated current of 40A for AC-1 and 25A for 440Vac in AC-3 conditions. This contactor is suitable for DIN rail mounting and has a net width of 45 mm. It offers a degree of protection rated at IP20 and operates within control voltage ranges of 38.4-52.8Vac at 50Hz and 40.8-52.8Vac at 60Hz, with a nominal control voltage of 48Vac. The rated operating voltage (Ue) is up to 690 V, and it features 1 normally open (NO) auxiliary contact and 1 normally closed (NC) auxiliary contact, both of the instantaneous type. The rated impulse voltage (Uimp) is 6 kV. Its rated active power reaches up to 15kW for 500Vac and 660-690Vac in AC-3 conditions. The contactor also supports rated power in horsepower, with capacities ranging from 2HP at 115Vac to 20HP at 575-600Vac across various configurations. It boasts a mechanical durability of 15 million operations at no load and an electrical durability of 1.6 million operations with load, ensuring its capability to handle phase-to-phase rated voltages up to 690 V.

Schneider Electric LC1D253N7 is a magnetic contactor from the Deca sub-range, featuring spring connections and designed with 3 poles (3P; 3NO). It has a rated current of 25A for both AC-1 and AC-3 (440Vac) applications. This contactor is suitable for DIN rail mounting and has a net width of 45 mm. It offers a degree of protection rated at IP20 and operates within control voltage ranges of 332-456Vac (415Vac nominal; 50Hz; 0.8...1.1 x Uc) and 353-456Vac (415Vac nominal; 60Hz; 0.85...1.1 x Uc). The rated operating voltage (Ue) is up to 690 V, and it includes 1 Normally Open (NO) auxiliary contact and 1 Normally Closed (NC) auxiliary contact, both of the instantaneous type (1NO+1NC). The rated impulse voltage (Uimp) is 6 kV. Its rated active power spans from 5.5kW at 220-230Vac to 15kW at 660-690Vac in AC-3 category. The rated power in HP varies from 2HP at 115Vac in single-phase to 20HP at 575-600Vac in three-phase applications, according to UL/CSA standards. The mechanical durability of the LC1D253N7 is rated at 15 million operations at no load, and its electrical durability is rated at 1.6 million operations with load. The rated voltage for phase-to-phase applications is 690 V.

Schneider Electric LC1D18CC7 is a magnetic contactor from the Deca sub-range, featuring screw connections and designed with 3 poles (3P; 3NO). It has a rated current of 32A for AC-1 and 18A for 440Vac in AC-3 conditions. This contactor is suitable for DIN rail mounting and has a net width of 45 mm. It offers a degree of protection rated at IP20 and operates within a control voltage range of 28.8-39.6Vac at 50Hz and 30.6-39.6Vac at 60Hz, with a nominal control voltage of 36Vac. The rated operating voltage (Ue) is up to 690 V, and it includes 1 Normally Open (NO) auxiliary contact and 1 Normally Closed (NC) auxiliary contact, both of the instantaneous type (1NO+1NC). The rated impulse voltage (Uimp) is 6 kV. Its rated active power spans from 4kW at 220-230Vac to 10kW at 660-690Vac in AC-3 conditions. The rated power in horsepower (HP) varies from 1HP at 115Vac in single-phase to 15HP at 575-600Vac in three-phase, according to UL/CSA standards. The mechanical durability of the LC1D18CC7 is rated at 15 million operations at no load, and its electrical durability is rated at 1.6 million operations with load. The rated voltage for phase-to-phase connections is 690 V.

Schneider Electric LC1D188R7 is a magnetic contactor from the Deca sub-range, featuring screw connections and a 4-pole (2NO+2NC) configuration. It has a rated current of 32A (AC-1) and is designed for DIN rail mounting with a net width of 45 mm. This contactor offers a degree of protection of IP20 and operates with a control voltage (AC) of 352-484Vac (440Vac nominal; 50Hz; 0.8...1.1 x Uc) and 374-484Vac (440Vac nominal; 60Hz; 0.85...1.1 x Uc). The rated operating voltage (Ue) is 690 V, and it includes 1 NO and 1 NC auxiliary contacts with a rated impulse voltage (Uimp) of 6 kV. The contacts type is 1NO+1NC instantaneous auxiliaries, and it boasts a mechanical durability of 15 million operations at no load. The rated voltage (AC) phase-to-phase is also 690 V.

Schneider Electric LC1D12J7 is a magnetic contactor from the Deca sub-range, featuring screw connections and designed with 3 poles (3P; 3NO). It has a rated current of 25A for AC-1 and 12A for 440Vac in AC-3 conditions. This contactor is suitable for DIN rail mounting and has a net width of 45 mm. It offers a degree of protection rated at IP20 and operates within a control voltage range of 9.6-13.2Vac at 50Hz and 10.2-13.2Vac at 60Hz. The LC1D12J7 is capable of handling a rated operating voltage (Ue) up to 690 V and includes 1 normally open (NO) auxiliary contact. It is designed to withstand a rated impulse voltage (Uimp) of 6 kV and can manage rated active power ranging from 3kW at 220-230Vac to 7.5kW at 660-690Vac in AC-3 conditions. Additionally, it features 1 normally closed (NC) auxiliary contact and supports various rated power (HP) specifications across different voltages and phases, including 0.5HP at 115Vac and up to 10HP at 575-600Vac. The LC1D12J7 boasts a mechanical durability of 15 million operations at no load and an electrical durability of 2 million operations with load, with a phase-to-phase rated voltage of 690 V.

Schneider Electric LC1D126R7 is a magnetic contactor from the Deca sub-range designed for efficient circuit control. It features ring-lugs connections and operates with 3-poles (3P; 3NO), supporting a rated current of 25A under AC-1 conditions and 12A at 440Vac under AC-3 conditions. This contactor is suitable for DIN rail mounting and has a net width of 45 mm. It offers a degree of protection rated at IP20 and operates with a control voltage (AC) range of 352-484Vac at 50Hz and 374-484Vac at 60Hz. The LC1D126R7 can handle a rated operating voltage (Ue) up to 690 V and includes 1 Normally Open (NO) auxiliary contact. It is capable of withstanding a rated impulse voltage (Uimp) of 6 kV and delivers rated active power outputs ranging from 3kW to 7.5kW across various AC-3 voltage levels. Additionally, it features 1 Normally Closed (NC) auxiliary contact with contacts type of 1NO+1NC instantaneous aux. The rated power (HP) varies from 0.5HP to 10HP across different voltages and phases, adhering to UL/CSA standards. Its mechanical durability is noted at 15 million operations at no load, and its electrical durability at 2 million operations with load. The rated voltage (AC) for phase-to-phase connections is 690 V.

Schneider Electric LC1D126P7 is a magnetic contactor from the Deca sub-range, designed for ring-lugs connections. It features 3 poles (3P; 3NO) and is rated for currents of 25A (AC-1) and 12A (440Vac; AC-3). This contactor is suitable for DIN rail mounting and has a net width of 45 mm. It offers a degree of protection rated at IP20 and operates with a control voltage (AC) range of 184-253Vac (230Vac nom.; 50Hz; 0.8...1.1 x Uc) and 195.5-253Vac (230Vac nom.; 60Hz; 0.85...1.1 x Uc). The rated operating voltage (Ue) is 690 V, and it includes 1 normally open (NO) auxiliary contact. The rated impulse voltage (Uimp) is 6 kV. Its rated active power spans from 3kW at 220-230Vac to 7.5kW at 660-690Vac (all AC-3), and it also features 1 normally closed (NC) auxiliary contact with contacts type of 1NO+1NC instantaneous aux. The rated power (HP) ranges from 0.5HP at 115Vac to 10HP at 575-600Vac, covering various configurations for single-phase and 3-phase systems under UL/CSA standards. It boasts a mechanical durability of 15 million operations and an electrical durability of 2 million operations with load, at a phase-to-phase rated voltage of 690 V.
