855-505/800-1001 WAGO Signal Conditioners

WAGO 855-505/800-1001 Plug-in current transformer; 800 A / 5 A
WAGO

Part#:855-505/800-1001

Manufacturer:WAGO

Product Lifecycle:Active

Get a quick Quote!

Plug-in current transformer; 800 A / 5 A

About the manufacturer: WAGO is one of the manufacturers that offers Signal Conditioners that you can order at Powermatic Associates site. WAGO is the global leader in spring clamp technology for electrical connections and ranks among the top suppliers of components for industrial and building automation. With 28 companies and 9 production facilities employing around 9,000 people worldwide, we ensure expert advice and close customer relationships.

Check out the 855-505/800-1001 WAGO price in the box on the right side or send a quick quote.

Product Details

  • Weight
    366.0000963 g
  • Country Of Origin
    Germany
  • HTS Code
    85043129900

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

855-505/800-1001 Description

Wago 855-505/800-1001 is a measurement current transformer (CT) designed for precise current measurement within electrical systems. It features CAGE-CLAMP spring connections for secure and maintenance-free connections. The design specification is 800/5A, with a rated power of 10 VA. This part operates without a specified supply voltage (AC) and is designed to function within an ambient air temperature range for operation of -5°C to +50°C and for storage from -25°C to +70°C. The rated insulation voltage (Ui) stands at 85 mm. It has a UPC code designated for surface or cable applications. The dimensions are H105.25mm x W85mm x D52mm, suitable for networks up to 800 A with a measurement accuracy for currents up to 5 A. The maximum current it can measure falls within Class 1 (Cl.1) accuracy.
