731-633/114-000 WAGO Electrical Connector Accessories

731-633/114-000 on Powermatic Associates
WAGO

Part#:731-633/114-000

Manufacturer:WAGO

Product Lifecycle:Active

Get a quick Quote!

1-conductor male connector; CAGE CLAMP®; 2.5 mm²; Pin spacing 7.62 mm; 3-pole; Snap-in flange; 2,50 mm²; orange

About the manufacturer: WAGO is one of the manufacturers that offers Electrical Connector Accessories that you can order at Powermatic Associates site. WAGO is the global leader in spring clamp technology for electrical connections and ranks among the top suppliers of components for industrial and building automation. With 28 companies and 9 production facilities employing around 9,000 people worldwide, we ensure expert advice and close customer relationships.

Check out the 731-633/114-000 WAGO price in the box on the right side or send a quick quote.

Product Details

  • Weight
    7.534001981 g
  • Country Of Origin
    Germany
  • HTS Code
    85366990990
  • Width
    1.627 inches, 41.32 millimeters
  • Weight
    7.534 grams
  • Strip Length
    0.35 inches, 9 millimeters
  • Voltage
    300 volts, 500 volts
  • Mounting Type
    Feed-through Mounting, Snap-in Flange
  • Package Type
    Box
  • Insulation Material
    Polyamide
  • Flammability Class
    V0
  • Height
    0.689 inches, 17.5 millimeters
  • Depth
    1.083 inches, 27.5 millimeters
  • Current
    12 amperes, 15 amperes
  • Country of Origin
    Germany
  • Contact Type
    Tin
  • Contact Material
    Copper
  • Connection Type
    For Conductor
  • Conductor Size
    12 american wire gauge, 2.5 millimeters
  • Color
    Orange
  • Actuator
    Operating Tool

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

731-633/114-000 Description

WAGO 731-633/114-000 is a connector part of the MCS - MULTI CONNECTION SYSTEM, designed without breaking capacity as specified in DIN EN 61984, indicating it should not be connected or disconnected under load or when live. It adheres to IEC/EN 60664-1 standards, with nominal voltages of 500V (III/3), 630V (III/2), and 1000V (II/2), all with a rated impulse voltage of 6kV and a rated current of 12A. UL and CSA approvals include ratings of 300V and 600V with currents up to 15A, depending on the use group. It features 3 connection points, a single connection type with CAGE CLAMP technology, and supports solid and fine-stranded conductors ranging from 0.08 to 2.5mm2. The connector has a 3-pole configuration, with a pin spacing of 7.62mm, and dimensions of 41.32mm in width, 17.5mm in height, and 27.5mm in depth. It offers variable coding, snap-in flange or feed-through mounting, and is made from Polyamide (PA66) in orange color, with a chrome-nickel spring steel clamping spring, and tin-plated electrolytic copper contacts. The part is RoHS compliant, has a temperature range of -60 to +100°C, and comes in boxes of 50 pieces with the country of origin being Germany.
