721-2203/037-000 WAGO Electrical Connector Accessories

721-2203/037-000 on Powermatic Associates
WAGO

Part#:721-2203/037-000

Manufacturer:WAGO

Category:Electrical Connector Accessories

Product Lifecycle:Active

Product description

721-2203/037-000 WAGO - 2-conductor female connector; Push-in CAGE CLAMP®; 2.5 mm²; Pin spacing 7.5 mm; 3-pole; 100% protected against mismating; Lateral locking levers; 2,50 mm²; light gray

Product Details

  • Weight
    9.774002571 g
  • Country Of Origin
    Poland
  • HTS Code
    85366990990
  • Width
    1.439 inches, 36.55 millimeters
  • Voltage
    300 volts, 500 volts
  • Weight
    9.774 grams
  • Strip Length
    0.39 inches, 10 millimeters
  • Package Type
    Box
  • Insulation Material
    Polyamide
  • Height
    0.819 inches, 20.8 millimeters
  • Depth
    1.173 inches, 29.8 millimeters
  • Current
    16 amperes, 20 amperes
  • Connection Type
    For Conductor
  • Flammability Class
    V0
  • Country of Origin
    Poland
  • Contact Material
    Copper Alloy
  • Contact Type
    Tin
  • Conductor Size
    12 american wire gauge, 2.5 millimeters
  • Color
    Gray
  • Actuator
    Operating Tool

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of 721-2203/037-000 on Powermatic Associates is $5.61. Order now.


About the product

WAGO 721-2203/037-000 is a connector part of the MCS - MULTI CONNECTION SYSTEM, designed without breaking capacity as per DIN EN 61984, indicating it should not be connected or disconnected under load or when live. It adheres to IEC/EN 60664-1 standards, with nominal voltages of 500V (III/3), 630V (III/2), and 1000V (II/2), all with a rated impulse voltage of 6kV and a rated current of 16A. UL and CSA approvals include ratings of 300V and 600V with currents ranging from 10A to 20A, depending on the use group. It features 6 connection points, 3 potentials, and utilizes Push-in CAGE CLAMP technology for connection, supporting solid and fine-stranded conductors of various sizes. The connector has a 3-pole configuration, with a pin spacing of 7.5mm, and dimensions of 36.55mm in width, 20.8mm in height, and 29.8mm in depth. It includes variable coding, anti-rotation protection, and mismating protection, with a locking lever for secure connection. The part is made from light gray Polyamide (PA66), with a flammability class of UL94 V0, and uses Chrome-Nickel spring steel and copper alloy for the clamping spring and contact material, respectively. It operates within a temperature range of -60 to +85°C, is RoHS compliant, and comes in boxes of 50 pieces with the country of origin being Poland.


This item can ship within 0 day!

Manufacturer warranty

721-2203/037-000 WAGO

$5.61

Your price can be lower.
Log in or Create account to check your discount

Stock:

0

Select Qty:

$5.61

$5.61 each

Worldwide Shipping and Delivery


Secure Payment Processing


Warranty
