RU20U-M12-LU8X2-H1141 Turck Ultrasonic Sensors
Part#:RU20U-M12-LU8X2-H1141
Manufacturer:Turck
Alt. Part#:100000282
Product Lifecycle:Active
Get a quick Quote!
RU20U-M12-LU8X2-H1141 Ultrasonic Sensor, Diffuse Mode Sensor
About the manufacturer: Turck is one of the manufacturers that offers Ultrasonic Sensors that you can order at Powermatic Associates site. Turck is a leading provider of sensor, fieldbus, and connectivity technologies, along with interface technology, human-machine interfaces (HMI), and RFID systems. We offer innovative solutions for factory and process automation requirements, guaranteeing top-notch performance.
Check out the RU20U-M12-LU8X2-H1141 Turck price in the box on the right side or send a quick quote.
Product Details
- Weight 45 g
- RoHS Yes
- Country Of Origin DEU
- HTS Code 8536507000
- Protection class IP67
- Housing surface Chrome-plated
- Ambient temperature -10…+60 °C
- Housing material Metal
- Electrical connection Connector, M12 × 1
- Output function Analog output
- Voltage output 0…10 V
- Operating voltage 15…30 VDC
- Housing quality CuZn
- Construction size M12 x 1
- Design Threaded barrel
- Radiation direction straight
- Range 25…200 mm
- Function Proximity
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
RU20U-M12-LU8X2-H1141 Description
Turck RU20U-M12-LU8X2-H1141 is an ultrasonic sensor from the RU20U series, designed with a 9° sonic cone diffuse mode for front sensing. This sensor features ultrasonic sensor TEACH-by-wire functionality and is constructed with a chrome-plated brass housing and a sensing face made of PET (Polyethylene terephthalate), PU (Polyurethane), and Epoxy. It comes pre-equipped with a 4-pin M12 Eurofast QD male connector for connectivity. The sensor operates on a supply voltage of 15-30Vdc, with 24Vdc nominal, and can function within an ambient air temperature range of -10°C to +60°C. It offers a degree of protection rated at IP67 and has a partially threaded cylindrical/barrel shape with an M12 thread size. The RU20U-M12-LU8X2-H1141 provides one digital output (15-30Vdc; PNP; fixed threshold) and one analog output (0-10Vdc), with a sensing distance ranging from 25-200mm. Its current consumption is 50mA under no-load conditions, and it features protection functions against short-circuit (pulsed) and reverse polarity. The measurement accuracy, or resolution, of this sensor is 0.5mm.
