RSC WKC 572-8M Turck Cordsets

Turck RSC WKC 572-8M RSC WKC 572-8M DeviceNet™ Cordset, Extension Cordset
Turck

Part#:RSC WKC 572-8M

Manufacturer:Turck

Alt. Part#:U-31557

Product Lifecycle:Active

In-stock parts: 1

Sep 28, 2024

RSC WKC 572-8M DeviceNet™ Cordset, Extension Cordset

About the manufacturer: Turck is one of the manufacturers that offers Cordsets that you can order at Powermatic Associates site. Turck is a leading provider of sensor, fieldbus, and connectivity technologies, along with interface technology, human-machine interfaces (HMI), and RFID systems. We offer innovative solutions for factory and process automation requirements, guaranteeing top-notch performance.

Check out the RSC WKC 572-8M Turck price in the box on the right side or send a quick quote.

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

RSC WKC 572-8M Description

Turck RSC WKC 572-8M is a DeviceNet double-ended cable/cordset featuring a 5-pin M12 eurofast male connector with a large plug body straight to a 5-pin M12 eurofast female connector with a large plug body at a 90�� angle. The cable is constructed with a nickel-plated brass coupling nut and a PVC jacket, measuring 7.2mm in cable sheath outer diameter and 8 meters (26 feet) in length. The gray sheathed cable has a rated current of 4A and a cross-section of 4 x #22AWG. It offers a degree of protection rated at IP68, NEMA 1, NEMA 3, NEMA 4, and NEMA 6P, with a rated voltage (AC) of 250Vac.

Related documents RSC WKC 572-8M Specs

RSC WKC 572-8M 777005240 (sheet_1).pdf

This item can ship within 24h!

Manufacturer warranty

$73.60

Stock:

1

Select Qty:

$73.60

$73.60 each

Worldwide Shipping and Delivery

Secure Payment Processing

Warranty

Responsive Customer Support
