RI-12HA4S1-2K1024-C1M Turck Encoders

Name: RI-12HA4S1-2K1024-C1M
Brand: Turck

Turck RI-12HA4S1-2K1024-C1M RI-12HA4S1-2K1024-C1M Incremental Encoder, Industrial Line

Part#:RI-12HA4S1-2K1024-C1M

Manufacturer:Turck

Alt. Part#:1545987

Product Lifecycle:Active

Get a quick Quote!

RI-12HA4S1-2K1024-C1M Incremental Encoder, Industrial Line

About the manufacturer: Turck is one of the manufacturers that offers Encoders that you can order at Powermatic Associates site. Turck is a leading provider of sensor, fieldbus, and connectivity technologies, along with interface technology, human-machine interfaces (HMI), and RFID systems. We offer innovative solutions for factory and process automation requirements, guaranteeing top-notch performance.

Check out the RI-12HA4S1-2K1024-C1M Turck price in the box on the right side or send a quick quote.

Product Details

Protection class
IP67
Output type
Incremental
Protection class shaft
IP67
Ambient temperature
-40…+85 °C
Housing material
Die-cast zinc
Flange type
Flange with mounting element
Shaft Type
Hollow shaft
Technology
Optical
Output function
Push-Pull 7272, with inverted signals
Electrical connection
Cable
Resolution, incremental
1024 ppr
Encoder line
Industrial-Line
Operating voltage
5…30 VDC

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

RI-12HA4S1-2K1024-C1M Description

Turck RI-12HA4S1-2K1024-C1M is a compact incremental rotary encoder designed for flange mounting with a long tether arm. It operates within an ambient air temperature range of -40 to +85°C and features a through hollow shaft flange design with optical sensing. This encoder is pre-wired with a radial 1m / 3ft cord with bare end flying leads, belonging to the Type RI-12 series. It has a 2" casing diameter and offers an IP67 degree of protection. The supply voltage ranges from 5Vdc to 30Vdc, supporting 6Vdc, 12Vdc, and 24Vdc, with a 300kHz pulse frequency. Constructed from die-cast metal housing, stainless steel shaft, butyl rubber shaft seal, stainless steel disc table, and stainless steel packing ring, it features a 5/8" hollow shaft bore. The encoder provides 1 x digital output (push-pull; 7272 compatible; 5Vdc-30Vdc) and includes protection functions against short-circuit, bearing lock, magnetic field, and reverse polarity. It can achieve a maximum rotational speed of 6000rpm, with a moment of inertia of 6 x 10-6kg.m2, and offers a resolution of 1024ppr (pulses/revolution). The current consumption is 50mA with no load, and it can withstand a maximum radial load of 80 N and a maximum axial load of 40 N.
