LS-551-0600-LIU24PN8X-H1181 Turck Level Sensors
Part#:LS-551-0600-LIU24PN8X-H1181
Manufacturer:Turck
Alt. Part#:100001866
Product Lifecycle:Active
Get a quick Quote!
LS-551-0600-LIU24PN8X-H1181 Level Sensor, With Analog Output and 4 × Switching Outputs
About the manufacturer: Turck is one of the manufacturers that offers Level Sensors that you can order at Powermatic Associates site. Turck is a leading provider of sensor, fieldbus, and connectivity technologies, along with interface technology, human-machine interfaces (HMI), and RFID systems. We offer innovative solutions for factory and process automation requirements, guaranteeing top-notch performance.
Check out the LS-551-0600-LIU24PN8X-H1181 Turck price in the box on the right side or send a quick quote.
Product Details
- Weight 1000 g
- Protection class IP67
- Ambient temperature -20…+60 °C
- Pressure resistance -1…10 bar
- Materials (contact with media) Stainless steel 1.4404 (AISI 316L), PTFE, FKM
- Communication protocol IO-Link
- Medium temperature -20…+100 °C
- Electrical connection Connector, M12 × 1
- Housing material Plastic, PBT
- Current output 4…20 mA
- Voltage output 0…10 V
- Operating voltage 12…30 VDC
- Measuring principle Guided microwave
- Probe length (L) 600 mm
- Output function NO/NC, PNP/NPN, analog output
- Process connection G 3/4'' male thread
- Medium liquids
- Detection type medium contact
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
LS-551-0600-LIU24PN8X-H1181 Description
Turck LS-551-0600-LIU24PN8X-H1181 is a sensor designed for liquid level measurement, belonging to the LS-5 series. This instrumentation level sensor/switch features a cylindrical shape with a housing made of PBT (Polybutylene Terephthalate) and wetted parts constructed from 1.4404 (316L) stainless steel. It has a measurement span of 600mm and is pre-equipped with an 8-pin M12 Eurofast QD male connector alongside a G3/4" threaded male process connection. The sensor operates within a pressure range of -1 to +10 bar (-14.5psi to +145psi) and requires a supply voltage of 12-30Vdc, with 24Vdc nominal. It is designed to function in ambient air temperatures ranging from -20°C to +60°C. The LS-551-0600-LIU24PN8X-H1181 offers an IP67 degree of protection and includes 1 x analog output (4-20mA / 0-10Vdc; can also be used as a NPN/PNP digital output) and 3 x digital outputs (NPN / PNP). Its response time is 400ms / 0.004 s.
