LZ1H2X4FU Schneider Electric Motor Control Starters

LZ1H2X4FU on Powermatic Associates

Schneider Electric

Part#:LZ1H2X4FU

Manufacturer:Schneider Electric

Product Lifecycle:Active

Get a quick Quote!

Schneider Electric LZ1H2X4FU is a starter from the Hybrid sub-range designed for asynchronous motors, combining contact and zero-voltage triac technologies. It features screw connections and is a 3-pole (3P) device with thermal overload protection class 10A. The rated current is 2.4A for AC-51 and adjustable from 0.18A to 2.4A for AC-53a. This unit is suitable for DIN rail mounting and has an IP20 degree of protection. It operates with a control voltage of 110-230Vac (50Hz/60Hz) and a rated operating voltage (Ue) of up to 500 V. It includes 1 Normally Open (NO) auxiliary contact and 1 Normally Closed (NC) auxiliary contact, with a contacts type of SPDT / 1C/O. The rated impulse voltage (Uimp) is 6 kV. Its rated active power is 0.37kW at 220/230Vac, 0.75kW at 380/400Vac, 415Vac, and 440Vac, and 1.1kW at 500Vac for AC-53a. The rated power in horsepower (HP) is 0.5HP at 208Vac and 220-240Vac, and 1HP at 440-480Vac for a 3-phase system under UL standards.

About the manufacturer: Schneider Electric is one of the manufacturers that offers Motor Control Starters that you can order at Powermatic Associates site. We provide digital solutions for energy and automation that improve efficiency and support sustainability. Our comprehensive solutions include cutting-edge energy technologies, real-time automation, software, and services for residential, commercial, and industrial settings.

Check out the LZ1H2X4FU Schneider Electric price in the box on the right side or send a quick quote.

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

LZ1H2X4FU Description

Schneider Electric LZ1H2X4FU is a starter from the Hybrid sub-range designed for asynchronous motors, combining contact and zero-voltage triac technologies. It features screw connections and is a 3-pole (3P) device with thermal overload protection class 10A. The rated current is 2.4A for AC-51 and adjustable from 0.18A to 2.4A for AC-53a. This unit is suitable for DIN rail mounting and has an IP20 degree of protection. It operates with a control voltage of 110-230Vac (50Hz/60Hz) and a rated operating voltage (Ue) of up to 500 V. It includes 1 Normally Open (NO) auxiliary contact and 1 Normally Closed (NC) auxiliary contact, with a contacts type of SPDT / 1C/O. The rated impulse voltage (Uimp) is 6 kV. Its rated active power is 0.37kW at 220/230Vac, 0.75kW at 380/400Vac, 415Vac, and 440Vac, and 1.1kW at 500Vac for AC-53a. The rated power in horsepower (HP) is 0.5HP at 208Vac and 220-240Vac, and 1HP at 440-480Vac for a 3-phase system under UL standards.

Manufacturer warranty

Get a quick Quote!

Request a quote, and we will send you price and availability within minutes.

Select Qty:

Average response time: 11 minutes

Worldwide Shipping and Delivery

Secure Payment Processing

Warranty

Responsive Customer Support
