ATV71HD37M3X337 Schneider Electric Variable Frequency Drives (VFD)

Schneider Electric

Part#:ATV71HD37M3X337

Manufacturer:Schneider Electric

Product Lifecycle:Active

Get a quick Quote!

Schneider Electric ATV71HD37M3X337 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the Altivar 71 series. It features sensorless flux vector control, ENA System Vector control with or without speed feedback, and can deliver 220% of the nominal motor torque for 2 seconds and 170% for 60 seconds. This model comes with a built-in heatsink in a coated version, operates on a supply voltage of 170-264Vac (200Vac / 220Vac / 230Vac / 240Vac nom.), and has dimensions of H550mm x W320mm x D266mm. It offers chemical resistance with a conformal coating (reinforced version) and has a degree of protection rated at IP20, IP21, and UL type 1. The rated current is 144A (230Vac; 2.5kHz) with a maximum current of 238A for 2 seconds and 216A for 60 seconds. Designed for wall mounting, it supports Modbus and CANopen communication protocols, operates on a 3-phase network, and has an output frequency range of 0.1-599 Hz. The unit includes 1 analog output (0-10Vdc / 0-20mA), 5 digital inputs (24Vdc; sink/source) plus 1 additional digital input programmable as discrete or PTC input and another for PWR safety, along with 1 digital output (C/O SPDT relay contact) and 2 digital outputs (NO relay contacts). It also features 1 analog input (-10...+10Vdc) and 1 analog input (0-10Vdc / 0-20mA), with a current consumption of 141A at 200Vac and 127A at 240Vac. The rated active power is 37kW, and the rated power is 50HP.

About the manufacturer: Schneider Electric is one of the manufacturers that offers Variable Frequency Drives (VFD) that you can order at Powermatic Associates site. We provide digital solutions for energy and automation that improve efficiency and support sustainability. Our comprehensive solutions include cutting-edge energy technologies, real-time automation, software, and services for residential, commercial, and industrial settings.

Check out the ATV71HD37M3X337 Schneider Electric price in the box on the right side or send a quick quote.

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

ATV71HD37M3X337 Description

Schneider Electric ATV71HD37M3X337 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the Altivar 71 series. It features sensorless flux vector control, ENA System Vector control with or without speed feedback, and can deliver 220% of the nominal motor torque for 2 seconds and 170% for 60 seconds. This model comes with a built-in heatsink in a coated version, operates on a supply voltage of 170-264Vac (200Vac / 220Vac / 230Vac / 240Vac nom.), and has dimensions of H550mm x W320mm x D266mm. It offers chemical resistance with a conformal coating (reinforced version) and has a degree of protection rated at IP20, IP21, and UL type 1. The rated current is 144A (230Vac; 2.5kHz) with a maximum current of 238A for 2 seconds and 216A for 60 seconds. Designed for wall mounting, it supports Modbus and CANopen communication protocols, operates on a 3-phase network, and has an output frequency range of 0.1-599 Hz. The unit includes 1 analog output (0-10Vdc / 0-20mA), 5 digital inputs (24Vdc; sink/source) plus 1 additional digital input programmable as discrete or PTC input and another for PWR safety, along with 1 digital output (C/O SPDT relay contact) and 2 digital outputs (NO relay contacts). It also features 1 analog input (-10...+10Vdc) and 1 analog input (0-10Vdc / 0-20mA), with a current consumption of 141A at 200Vac and 127A at 240Vac. The rated active power is 37kW, and the rated power is 50HP.

Manufacturer warranty

Get a quick Quote!

Request a quote, and we will send you price and availability within minutes.

Select Qty:

Average response time: 11 minutes

Worldwide Shipping and Delivery

Secure Payment Processing

Warranty

Responsive Customer Support
