UCX06-103D1 NSK Mechanical Components

UCX06-103D1 on Powermatic Associates
NSK

Part#:UCX06-103D1

Manufacturer:NSK

Product Lifecycle:Active

Get a quick Quote!

Insert Bearing; 1-3/16" Bore; 1.689" Length Thru Bore; Wide Inner Ring; 0.787" Outer Race Width; Spherical; 2.835" Outside Diameter; Relubricatable; Single Lip Contact Land Riding Seal; Set Screw Mounting Method; No Snap Ring; Ball Bearing Rolling Element

About the manufacturer: NSK is one of the manufacturers that offers Mechanical Components that you can order at Powermatic Associates site. NSK embarked on its journey by producing Japan's first bearings in 1916. Since then, it has evolved into a global entity focused on researching, designing, and manufacturing Motion & Control™ solutions crucial for mobility and industrial applications. NSK holds the position of the leading bearing supplier in Japan and ranks as the third largest supplier worldwide by market share. Our innovative products and technologies boost automotive performance and industrial productivity while significantly lowering energy consumption. In the early 1960s, we expanded our horizons beyond Japan, establishing over 200 business locations across 30 countries and forming an extensive network of joint ventures and partnerships worldwide.

Check out the UCX06-103D1 NSK price in the box on the right side or send a quick quote.

Product Details

  • Outside Diameter
    2.835 Inch | 72 Millimeter
  • Length Thru Bore
    1.689 Inch | 42.9 Millimeter
  • Bore
    1.188 Inch | 30.175 Millimeter
  • Outer Race Width
    0.787 Inch | 20 Millimeter
  • Other Features
    Single Row | Medium Duty | Steel Cage
  • Inch - Metric
    Inch
  • Snap Ring
    No
  • Rolling Element
    Ball Bearing
  • Mounting Method
    Set Screw
  • Outer Race Profile
    Spherical
  • Weight / Kilogram
    1.5
  • Seal Type
    Single Lip Contact Land Riding
  • Brand
    NSK
  • Relubricatable
    Yes
  • CATEGORY
    Insert Bearings Spherical OD
  • Inner Race Profile
    Wide Inner Ring
  • Minimum Buy Quantity
    N/A

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
