H300-03400062A10101AB103 Nidec Variable Frequency Drives (VFD)

H300-03400062A10101AB103 on Powermatic Associates
Nidec

Part#:H300-03400062A10101AB103

Manufacturer:Nidec

Category:Variable Frequency Drives (VFD)

Product Lifecycle:Active

Product description

NIDEC H300-03400062A10101AB103 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the H300 series designed with a built-in brake transistor, internal line choke, and air cooling. It features dimensions of frame size 3, measuring H15" x W3.3" x D7.9" (H382mm x W83mm x D200mm), and operates on a 3-phase input network with a supply voltage range of 380Vac-480Vac (400Vac / 415Vac). This model supports Modbus RTU communication protocol and is capable of operating within an ambient air temperature range of -20°C to +40°C. It offers a degree of protection rated at IP20 NEMA 1 UL type 1. The drive has a rated current of 6.2A under normal duty, network frequency of 60 Hz, and provides 2 analog outputs, 6 digital inputs (3 of which are configurable), and 2 digital outputs (relay contact type). Additionally, it includes 2 analog inputs (1 x 4-20mA and 1 x 0-10Vdc), with a rated active power of 2.2kW and rated power of 3HP under normal duty conditions.

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
