VZBA-1-GG-63-T-22-F0405-V4V4T-PP30-R-90-C

Festo VZBA-1-GG-63-T-22-F0405-V4V4T-PP30-R-90-C is a pneumatically actuated valve made from stainless steel 1.4401/1.4404 (AISI 316L)/1.4408 for the housing and shut-off element, with PTFE-reinforced seals, designed for high corrosion stress (CRC 3). It operates within an ambient air temperature range of -10 to +80°C and features in-line installation with DN25 nominal width. The connection type is 2 x Rp1" pipe threaded according to DIN EN 10226-1. This valve delivers a torque of 30Nm, supported by a built-in rotary actuator, and operates at a nominal pressure of 63bar for the process valve, with an operating pressure range of +6 to +8.4bar. It offers a flow rate of 71.5m3/h (Kv) and is designed with a built-in double-acting quarter-turn actuator, two bolt circles with diameters of 42mm and 50mm, closed end-position adjustment, and a 3-part design. It is ATEX compliant, suitable for ball valve applications with a 90° swivel angle (right direction), and can handle compressed air (-10°C to +200°C) in accordance with ISO 8573-1/2010 [7;4;4], inert gases, neutral fluids, or water as input mediums. The valve function is 2/2-way with 2-ports and 2-positions, categorized under the VZBA series.
